Roller Die Wire Drawing Machine

Roller Die Wire Drawing Machine thumbnail-1
Roller Die Wire Drawing Machine thumbnail-2
Roller Die Wire Drawing Machine thumbnail-3
Roller Die Wire Drawing Machine thumbnail-4
Roller Die Wire Drawing Machine thumbnail-5
Roller Die Wire Drawing Machine thumbnail-6
Roller Die Wire Drawing Machine photo-1
Roller Die Wire Drawing Machine photo-2
Roller Die Wire Drawing Machine photo-3
Roller Die Wire Drawing Machine photo-4
Roller Die Wire Drawing Machine photo-5
Roller Die Wire Drawing Machine photo-6
US$ 35,000 - 70,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Zhangjiagang City Wanyi Machine Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or as u need
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Place of Origin Jiangsu, China
Brand Name wanyi
Model Number straight line
Voltage 380v
Power(W) 11KW each block
Dimension(L*W*H) 8000X1650X1500MM
Weight 9500kg
Certification third part
Warranty one year freely
After-sales Service Provided Overseas service center available

roller die wire drawing machineroller die wire drawing machineroller die wire drawing machine1.Equipment constituter: (1) up-draft pay-off rack

                    (2)LZ7/600 straight line drawing machine

                    (3)600 trunk type take up machine

                     (4 ) human machine interface display screen

                     (5) Whole set of electrical appliance control cabinet

2. Work areas:   (1) input diameter: 6.0 or 5.5 mm

              (2)input strength: 500Mpa or less

              (3) input material: low and high carbon wire,CO2 wire,flux-cored wire  and so on

              (4) output diameter: 2.0--2.4mm

3. Drawing speed: (1) max: 10m/s   (2) average: 8m/s with output 8.5t/d (10h per day)

4. Water- air pressure: (1) hydraulic pressure 0.2Mpa  or more(2) barometric pressure>0.5Mpa

5. Electric motor standard: (1)drawing machine: 22KW  AC motor

                    (2) wire coiling machine: 15KW  AC motor

6. Reel form: (1) diameter: 600mm

           (2) Material: ZG45 steel, surface spray finishing with carbonized tungsten alloy powder, hardness more than HRC60, surface roughness concentration less than 1.6Ra

           (3) Service life: 10000h

roller die wire drawing machine
