Home > Products > Heat Treating Winder > annealing furnace
annealing furnace
- 3 Set / Sets per Month
- Shanghai or your needs
Product Details
Condition: | New | Type: | Arc Furnace | Usage: | Holding Furnace |
Place of Origin: | Jiangsu, China | Brand Name: | wanyi | Model Number: | pit type |
Voltage: | 380V | Power(W): | 0-400kw | Dimension(L*W*H): | Custom Made |
Weight: | 5000-8000kg | Certification: | SGS | Warranty: | one year freely |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Parameter of furnace
1, The power 240kW+10%
2, Voltage 380V,3ph,50Hz
3, Max temperture 650°C
4, Heating element connetion way Y Y
5, Temperture control zone number 2 zones
6, Loading weight 2350KG
7, Empty loss power ≤10kW
8, Empty temperture heating time ≤2.5h
9, Temperture uniformity ±5°C
10, Temperture stability ≤±1°C
11, The size of outside 4.35X3.44X5.5M
12, The valid size for loading 3.05X2.4X2.1M
Main compoments and materials list
Name | Size and decription |
Cycle fan | WGB |
Reconding instruments | XWGJ-101 |
Temperature control instrumentation | FP93 |
Thermocouple | WRN-100 K |
Auto air switch | DZ ,FM |
Automatic circuit breakers | DW |
AC contactor | CJ20 |
Fast fuse | RSO |
Steel | Q235 |
Heating elements | 0Cr25Al5 |
Refractory | NG-1.3,0.6 |
Aluminosilicate refractory fiber | standard |
