AL Alloy Wire Drawing Machine
US$ 20,000 - 70,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
Inlet Diameter:
9.5
Outlet Diameter:
2.3
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or as u need
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Aluminum Wire Drawing MachineUS$ 20,000 - 70,000MOQ: 1 Set -
Aluminium Alloy Wire Drawing MachineUS$ 25,000 - 60,000MOQ: 1 Set
-
Alloy Wire Drawing MachineUS$ 30,000 - 60,000MOQ: 1 Set
-
Low Carbon Straight Type Wire Drawing MachineUS$ 20,000 - 70,000MOQ: 1 Set
-
Brass Wire Drawing MachineUS$ 20,000 - 80,000MOQ: 1 Set
Inlet Diameter
9.5
Outlet Diameter
2.3
Place of Origin
Jiangsu, China
Brand Name
WANYI
Model Number
LZ600
Voltage
380/220V
Power(W)
15KW each
Dimension(L*W*H)
7.5X1.5X1.5M
Weight
6000kg
Certification
third parts, third parts (CE or SGS so on)
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
technical parameters
| height | 5000mm( not easy to be tangled) |
| Max inlet coiler diameter | Ø2000mm(4000kg) |
| capstan diameter | Φ600mm |
| capstan quantity | 3 |
| wire tangle alarming and stop line device | yes |
| rod straightening function | yes |
pointing and threading unit
it is used to sharpend the rod and thread it through the dies
| roller diamter | Φ100mm |
| roller speed | 24r/min |
| diameter | Φ1.5mm-Φ12mm |
| drum diameter | Φ420mm |
| main motor | 5.5 kw/AC |
wire drawing machine
material and frame ironed cast, two sets DC motor, bearing brand are NSK, gear material is 20CrMnTi, tooth surface is hard, capstan coating tungsten carbidem dies frame is casting, outlet die is rotatable, capstan type is double taper,cover matrial is stainless steel
| inlet diameter | Ø9.5mm |
| outlet diameter | Φ2.3(1.8)-Φ4.5mm |
| capstan diameter | Φ450mm |
| Max. drawing speed | Max 25m/s |
| speed ratio between captans | 1.238 13st is adjustable |
| Max dies No. | 13 |
| dies holder size | ITO standard Φ53mm*35mm |
| capstan surface treatment | tungsten carbide |
| Main motor | 315 KW/1000r/min DC |
| fix speed capstan motor | 75KW/1500r/min DC |
| the machine noise | ≤85db |
| protection cover | stainless steel double layer |
| inlet guide roller | yes |
user prepare section
civil work and outside pipe and wire work
drawing oil and lubrcation oil
cooling water tank with recycle system
the whole dies for test run
bobbin and Al rod
power supply wire and cable
butt welder
air source more than 0.6Mpa
