Top Quality High Intensity Dry Magnetic Separator Directly From Manufacturer

Top Quality High Intensity Dry Magnetic Separator Directly From Manufacturer photo-1
Top Quality High Intensity Dry Magnetic Separator Directly From Manufacturer photo-2
Top Quality High Intensity Dry Magnetic Separator Directly From Manufacturer photo-3
Top Quality High Intensity Dry Magnetic Separator Directly From Manufacturer photo-4
Top Quality High Intensity Dry Magnetic Separator Directly From Manufacturer photo-5
Top Quality High Intensity Dry Magnetic Separator Directly From Manufacturer photo-6
US$ 1,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Magnetic Separator, high intensity dry Magnetic separator
Production Capacity:
5-100 T/H
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Magnetic Separator, high intensity dry Magnetic separator
Production Capacity 5-100 T/H
Place of Origin Henan, China
Brand Name Lanji
Model Number 1230
Voltage 220/380V
Power(W) 1.1-11 Kw
Dimension(L*W*H) 1.5*1.2*3.0
Weight 0.8-9.8 T
Certification ISO9001
Warranty 2 Years, 1 year
After-sales Service Provided Overseas service center available

Top quality high intensity dry Magnetic separator directly from manufacturer



Product Description





1. magnetic separator features:



1. Widely used: to complete more than 30 mineral processing of iron needs;
2. Operation is simple: one person can complete the entire magnetic separation process;
3. Save costs: low energy consumption and saving over the past more than 45% magnetic separation equipment;
4. Poor in iron, broken or crushed by the thick rough after the election, remove rock and other waste rock, improve quality, reduce the load on the

2. Main Technical Parameter  of  Dry Magnetic Seperator





Model

Diameter (mm)

Length (mm)

Capacity (t/h)

Revolutions (rpm)

Power

 (kw)

Weight

(kg)

CTB606

600

600

8-15

40

1.1

867

CTB612

600

1200

16-29

40

1.5

1321

CTB618

600

1800

18-35

40

1.5

1655

CTB712

700

1200

12-30

35

2.2

1682

CTB718

700

1800

20-45

35

2.2

1992

CTB918

900

1800

28-60

27

4

3162

CTB924

900

2400

37-80

27

4

3887

CTB930

900

3000

45-95

27

5.5

4235

CTB1018

1050

1800

36-72

22

4

3801

CTB1021

1050

2100

45-85

22

4

4165

CTB1024

1050

2400

52-100

22

5.5

4319

CTB1030

1050

3000

64-125

22

7.5

4976

CTB1218

1200

1800

55-95

19

7.5

5263

CTB1224

1200

2400

65-110

19

7.5

5927

CTB1230

1200

3000

85-120

19

7.5

6325

CTB1530

1500

3000

95-160

16

11

8665

CTB1540

1500

4000

120-190

16

11

9871





Top quality high intensity dry Magnetic separator directly from manufacturerTop quality high intensity dry Magnetic separator directly from manufacturer

Top quality high intensity dry Magnetic separator directly from manufacturer




Packaging & Shipping

 Small size will be packed by standard export wooden case; medium size will be packed by container and large size will be shipped in bulk.


Our Services

We can send engineers to buyer's site for guiding installation.


Company Information

Top quality high intensity dry Magnetic separator directly from manufacturer


FAQ

1. Please tell us your main raw material for processing?

2. Please tell us the input size?

3. Please tell us the processing capacity you need?

4. Please tell us is your or Fe3O4 or Fe2O3?



Thanks so much for you taking time to browse our high intensity dry magnetic separator. Any further questions, please feel free to contact us and we are ready to so service for you! Small
