Mining gravel vibrating sieve
Vibrating Screen is widely used for grading and screening materials in the following fields: minerals, quarry, building materials, water conservancy and hydropower, transportation, chemical industry, smelting and so on.
INTRODUCTION
- Mining vibrating sieving machine is a new type vibrating screen . It is especially designed for quarry to separate stone.YZ,YK series are characterized by advanced structure,strong excited force,low noise,easy maintenance,firm and durable design,etc.
- Mining vibrating sieving machine is widely used for grading production in mines ,building materials ,transportation ,energy and chemical industry ,etc .
Advantages
- Because of strong vibration of sieve box, it reduces the phenomenon that materials block the sieve, and make the sieve high screening efficiency and productivity.
- Simple structure ,easily removable screen surface
- Low power consumption per ton of material when screening
Technical parameters of mining vibrating sieving machine
Model |
Layers |
Screen Size (M2) |
Sieve Size (mm) |
Max Feed Size(mm) |
(m3/h) |
Frequency Power (r/min) |
Double amplitude(mm) |
Motor Power (kw) |
Screen surface |
Screen surface specification(MM) |
Weight(kg) |
2YK1225 |
2 |
6 |
4-50 |
400 |
8-60 |
800-970 |
8 |
5.5 |
20 |
1200×2500 |
2500 |
3YK1225 |
3 |
9 |
4-50 |
400 |
10-70 |
800-970 |
8 |
5.5 |
20 |
1200×2500 |
2850 |
2YK1230 |
2 |
7.2 |
4-50 |
400 |
12-78 |
800-970 |
8 |
7.5 |
20 |
1200×3000 |
3000 |
3YK1230 |
3 |
10.8 |
4-50 |
400 |
13-80 |
800-970 |
8 |
7.5 |
20 |
1200×3000 |
3600 |
2YK1237 |
2 |
8.88 |
4-50 |
400 |
15-86 |
800-970 |
8 |
7.5 |
20 |
1200×3700 |
3600 |
3YK1237 |
3 |
13.22 |
4-50 |
400 |
16-90 |
800-970 |
8 |
7.5 |
20 |
1200×3700 |
4200 |
2YK1535 |
2 |
10.5 |
5-50 |
400 |
20-125 |
800-970 |
8 |
11 |
20 |
1500×3500 |
4890 |
3YK1535 |
3 |
15.75 |
5-50 |
400 |
21-125 |
800-970 |
8 |
11 |
20 |
1500×3500 |
5700 |
