Home > Products > Screen Plant > High capacity stone vibrating screen machine
High capacity stone vibrating screen machine
- 100 Set / Sets per Month
- Qingdao Shanghai
- T/T L/C D/P D/A Credit Card
Product Details
| Condition: | New | Type: | Circular | Application: | Ore |
| Place of Origin: | Henan, China | Brand Name: | Lanji | Model Number: | 2YK2460 |
| Voltage: | 380v | Power(W): | 37kw | Dimension(L*W*H): | 7450*3230*1500 |
| Weight: | 15600kg | Certification: | ISO9001 | Warranty: | 1year |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High capacity stone vibrating screen machine
1. Brief introduction of stone vibrating screen
LanJi Circular Vibrating Screen is widely applied in coal dressing, ore dressing, building material, electricity and chemical industries. It is doing circular movement while at work, and it is of a highly-effective, newly-developed and multilayer machine. With the introduction of eccentric shaft vibration exciter and particular block, the amplitude can be adjustable. Meanwhile, such screen has features of reliable structure, strong excited force, perfect separating efficiency, low noise, long life span, large handling capacity, and durable usage.
2. Technical parameters of stone vibrating screen:
Model | Sieve lay-er | Sieve area (m2) | Mesh size (mm) | Max feedin-g size (mm) | Capacity (m3/h) | Vibrating frequency (r/min) | Motor power (kw) | Weight (kg) | Sieve spec. (mm) |
YK1236 | 1 | 4.2 | 3-100 | 300 | 30-160 | 970 | 5.5 | 3210 | 1180×3550 |
3YK1236 | 3 | 4.2 | 3-100 | 300 | 30-160 | 970 | 11 | 4110 | 1180×3550 |
2YK1245 | 2 | 5.3 | 3-100 | 300 | 35-180 | 970 | 11 | 4320 | 1180×4450 |
3YK1245 | 3 | 5.3 | 3-100 | 300 | 35-180 | 970 | 11 | 4460 | 1180×4450 |
YK1535 | 1 | 5.1 | 3-100 | 300 | 34-200 | 970 | 11 | 4680 | 1480×3450 |
3YK1535 | 3 | 5.1 | 3-100 | 400 | 34-200 | 970 | 15 | 5710 | 1480×3450 |
YK1545 | 1 | 6.6 | 3-100 | 400 | 44-200 | 970 | 11 | 4300 | 1480×4450 |
2YK1545 | 2 | 6.6 | 3-100 | 400 | 44-258 | 970 | 15 | 4830 | 1480×4450 |
3YK1545 | 3 | 6.6 | 3-100 | 400 | 44-258 | 970 | 15 | 5832 | 1480×4450 |
4YK1545 | 4 | 6.6 | 3-100 | 400 | 44-258 | 970 | 18.5 | 6070 | 1480×4450 |
3YK1548 | 3 | 7.03 | 3-100 | 400 | 47-275 | 970 | 15 | 6540 | 1480×4750 |
4YK1548 | 4 | 7.03 | 3-100 | 200 | 47-275 | 730 | 18.5 | 6850 | 1480×4750 |
YK1848 | 1 | 8.5 | 3-100 | 400 | 56-330 | 755 | 15 | 6189 | 1780×4750 |
2YK1848 | 2 | 8.5 | 3-100 | 400 | 56-330 | 750 | 18.5 | 6539 | 1780×4750 |
3YK1848 | 3 | 8.5 | 3-100 | 400 | 56-330 | 970 | 22 | 6935 | 1780×4750 |
2YK1854 | 2 | 9.5 | 3-100 | 400 | 63-450 | 970 | 22 | 7220 | 1780×5350 |
3YK1854 | 3 | 9.5 | 3-100 | 400 | 63-450 | 970 | 22 | 7640 | 1780×5350 |
YK1860 | 1 | 10.6 | 3-100 | 400 | 56-450 | 970 | 18.5 | 7200 | 1780×5950 |
2YK2160 | 2 | 12.4 | 3-100 | 400 | 80-720 | 970 | 30 | 8240 | 2080×5950 |
3YK2160 | 3 | 12.4 | 3-100 | 400 | 80-720 | 970 | 30 | 8800 | 2080×5950 |
2YK2460 | 2 | 14.2 | 3-100 | 400 | 80-800 | 970 | 30 | 9120 | 2380×5950 |
3YK2460 | 3 | 14.2 | 3-100 | 400 | 80-800 | 970 | 30 | 9600 | 2380×5950 |
