High Capacity Gold Ore Washing Wet Trommel Screen

High Capacity Gold Ore Washing Wet Trommel Screen thumbnail-1
High Capacity Gold Ore Washing Wet Trommel Screen thumbnail-2
High Capacity Gold Ore Washing Wet Trommel Screen photo-1
High Capacity Gold Ore Washing Wet Trommel Screen photo-2
US$ 5,000 - 16,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Circular, rolling screen,rotary screen,trommel screen
Application:
Ore
Contact Supplier Request Quote Chat Now
Henan Lanji Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Circular, rolling screen,rotary screen,trommel screen
Application Ore
Place of Origin Henan, China
Brand Name Lanji
Model Number 400*800-1250*2500mm
Voltage 380v
Power(W) refer to specification
Dimension(L*W*H) refer to specification
Weight refer to specification
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

gold trommel screen:

1)High screening efficiency

2)Long bearing lifetime

3)Fast delivery







High capacity gold ore washing  wet trommel screen   :

trommel screen/rolling screen application:

  trommel screen is suitable to screen materials which are wet and easy blocking : sand gold ore,coal,coke,lime ,etc. largest screened sizeis 100mm,middle size is 10-50mm,  fine size is below 3mm. Trommel screen is suitable for classifying powdery materials with outstanding screening effect. The screen mesh is 60-200; power is 0.75-3kw and output is 500-1500kg/h.

structure drawing:



High capacity gold ore washing wet trommel screen



trommel screen main features:

1. Stable operation



2. High screening efficiency



3. Big output



4. Convenient installation



 High capacity gold ore washing wet trommel screenHigh capacity gold ore washing wet trommel screen



trommel screen main features:

Model

Specification

(m)

Slope

Rotary speed

Sieve pore(mm)

Max feeding size (mm)

Production capacity(m3/h)

Motor power

(kw)

Sieve pore(2mm)

Sieve pore(20mm)

GTS820

Φ0.8X2

6°

32

2-20

Mesh size X2.5

7

30

3

GTS830

Φ0.8X3

6°

32

2-20

Mesh size X2.5

8

50

3

GTS1030

Φ1X3

6°

25

2-20

Mesh size X2.5

10

60

4

GTS1040

Φ1X4

6°

25

2-20

Mesh size X2.5

11

80

4

GTS1230

Φ1.2X3

6°

20

2-20

Mesh size X2.5

12

100

5.5

GTS1240

Φ1.2X4

6°

20

2-20

Mesh size X2.5

14

120

5.5

GTS1250

Φ1.2X5

6°

20

2-20

Mesh size X2.5

15

140

5.5

GTS1530

Φ1.5X3

6°

17

2-20

Mesh size X2.5

16

120

5.5

GTS1540

Φ1.5X4

6°

17

2-20

Mesh size X2.5

18

150

7.5

GTS1550

Φ1.5X5

6°

17

2-20

Mesh size X2.5

20

180

11

GTS1560

Φ1.5X5

6°

17

2-20

Mesh size X2.5

22

200

11



 High capacity gold ore washing wet trommel screenHigh capacity gold ore washing wet trommel screen
