Specifications
the feature of concentrator machine1.simple structure
2.lower power construction
3.easy operation
4.high technical standard
Mining concentrating machine for ore production line
High efficiency concentrator:
Applicable to concentrator concentrates and tailings dewatering, is widely used in metallurgy, chemical industry, coal, nonmetallic mineral processing, environmental protection and other industries.The High efficiency concentrator machine of our company is suitable for dehydrating water of the concentration and gangue in the concentrating factory which can make the mash of 20to30% raise up to 40to70% about.Efficient Thickener settlement actually is not a simple device, but a combination of the mud layer filtering feature a new type of dehydration equipment.
High efficiency concentrator working principle:
Concentration (high efficiency concentrator) General mainly concentrated pool, DCB frame, transmission device, DCB frame to enhance device, feeding device, discharging device and signal safety devices, etc.. Concentrated machine (high efficient enrichment machine) The main features of the work to be concentrated in the pulp to add a certain amount of flocculant , so that the pulp of the ore to form floc particles to accelerate their settling velocity, thus to improve the enrichment efficiency.
High efficiency concentrator feature:
1.Adding flocculating agent, bigger the diameter of the deposit solid grain, speed up the deposit.
2.Set the lean board, reduce the mash deposit distance, increase the deposit square.
3.Have effect on flocculating. Percolating, compressing and dealing quantity of the slurry deposits
4. Fit the perfect automatic facility.
Technical Data:
Model | Concentration pond(m) | Deposit square | Harrow part | Motor | Capacity | Weight | |||||
Model | Specif-ication | Inner dia. | Depth | Pond degree | Method | Height | Rotation time | Driving | Lifting | ||
NZS-1 | Ø1.8m | 1.8 | 1.8 | 2.54 | Manual | 0.16 | 2 | Y90L-6 1.1kw |
| 5.6 | 1.235 |
NZS-3 | Ø3.6m | 3.6 | 1.8 | 10.2 | Manual | 0.35 | 2.5 | Y90L-6 1.1kw |
| 22.4 | 3.064 |
NZS-6 | Ø6m | 6 | 3 | 28.3 | Manual | 0.2 | 3.7 | Y90S-4 1.1kw |
| 62 | 8.751 |
NZSF-6 | Ø6m | 6 | 3 | 28.3 | Manual |
| 3.7 | Y90S-4 1.1kw |
| 62 | 3.649 |
NZ-9 | Ø9m | 9 | 3 | 63.6 | Auto | 0.25 | 4.34 | Y132S-6 3kw | XWD0.8-3 0.8kw | 140 | 6.134 |
NZS-9 | Ø9m | 9 | 3 | 63.6 | Manual | 0.25 | 4.34 | Y132S-6 3kw |
| 140 | 5.146 |
