Sawdust pellet making machine :
Vertical ring die straw pellet machine is mainly composed of power system, granulating chamber, engine base, lubrication system, dedusting system and electric control system.
1). Power system
Power system is composed of Y series motor, coupling, and high-power reduction gear. Reduction gear uses sound absorption box structure, large surface area and large fan. Advanced gear grinding technology improves the reliability of rising temperature, reducing noise, and running, so the transmitted power is increased.
2) Granulating chambe
Granulating chamber is composed of bearing chamber, bearing, main shaft, ring die, compression roller, and cutting device.
Material of moisture content 8-10% reaches granulating chamber passing by feed inlet by feeding mechanism. Transmission main shaft drives two compression rollers rotating. Material is squeezed into ring die hole due to the rotation and squeeze of compression roller and shapes up in the die hole and is squeezed out of the die hole. And then, the forming particles are cut into required length by cutting device and outflow the machine by stirring of cutting device.
3)Engine base
Engine base uses thick steel plate and is treated by welding, aging treatment, boring-milling, so engine base strength increases and assembly accuracy of power system and granulating chamber is guaranteed.
4)Lubrication system
The lubrication system is automatic. Lubricating grease is pushed into main shaft oil hole, lubrication roller bearing and main shaft bearing by electric petrol pump. This system can set injection time and injection time interval automatically according to customers’ different requirement.
5)Dedusting system
The dusting system is set around granulating chamber. Dust is sucked into spiral dust remover by pipeline when material enters granulating chamber. Spiral dust remover is optional.
6)Electronic control system
Electric control system has to be specially designed according to customers’ request.
sawdust pellet making machine technical parameters:
Type | Capacity | Power | Production Size | Weight | Size |
(T/H) | (KW) | (MM) | (T) | (MM) | |
ZL450 | 0.5-0.7 | 45 | Φ4-12 | 5.5 | 2600x1200x2300 |
ZL560 | 1-1.5 | 90 | Φ4-12 | 6 | 2600x1300x2310 |
ZL850 | 2-3 | 220 | Φ4-12 | 13.5 | 3380x1480x3180 |
ZL1050 | 5-6 | 355 | Φ4-30 | 22 | 4200x1850x3680 |
ZL1250 | 8-9 | 415 | Φ4-30 | 25 | 4600x1950x3880 |
