1.The new generation of Dongfeng Tianjin is used as bearing chassis. The vehicle is environment-friendly, fuel-efficient, oil saving, safe, comfortable, reliable and powerful.
2.Asphalt storage tank is covered with insulation cotton and inside wall is coated with high temperature insulation coatings(the only one in china). The heat preservation effect is better and more lasting.
3.High power diesel engine is used as auxiliary power. The performance is more reliable and it is safer to use.
4.The spreading process is monitored by computer. And according to the real-time speed, the hydraulic flow is adjusted, which ensures spreading accuracy.
5.Large-screen touch LCD human-machine interface, menu operation, Chinese and English language selection, and man- machine communication are more friendly . It is easier to operate.
6.Temperature control module always monitors temperature of heat conduction oil. Danger caused by high temperature and overheating of heat conduction oil can be avoided. It is safer.
7.PTO power take-off method is used . Zero distance spraying can be realized.
8.Three overlapping spraying ensures more uniform spreading with higher precision.
Techinical parameters
MODEL | ZQZ5162GLQ | CHASSIS MODEL | DFL1160BX |
Total Weight(kg) | 16000 | Tyre | 9.00-20&10.00-20 |
kerb weight(kg) | 9750 | Wheelbase(mm) | 5000 |
Rated Load Weight (kg) | 6055 | Tread(mm) | 1880/1800 |
Dimension(mm) | 8998*2490*3200 | Min. Ground Clearance(mm) | 250 |
Tank Capacity(m3) | 8 | Burner | G20 |
Spray Width(mm) | 6000 | Asphalt Pump | QGB450 |
Spray Value(kg) | 0.5-3.0 | Generator(Converter) | EC6500CX |
Insulation Thickness(mm) | 50 | Max. Truck Speed(km/h) | 90 |
Nozzles | 39 | Axis No. | 2 |
Hydraulic Motor | L2F63W2P2 | Hydraulic Pump Model | CBQ-F540 |
ASPHALT DISTRIBUTOR
1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight
2. MOQ:
No requirement for testing and trial order
3. Handling time for an order:
Within 10 days supplied from stock
4. Shipping way:
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
5. Quality Control:
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
6. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time
c. Free replacement will provide once the failure confirmed caused by our product quality.
