Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Concrete Machinery > Upper Bitumen Sprayer Truck for Sale Manufactures
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
ICOM
Model Number:
ZM-8SPSZ
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Bitumen Pressure Distributor Sprayer PriceNegotiableMOQ: 1 Piece -
Secmair Chip Sealer41 for Sale Manufacture in ChinaUS$ 100,000 - 150,000MOQ: 1 Set
-
Bitumen Spraying Equipment Ltd From CHINA IKOMNegotiableMOQ: 1 Set
-
Hot Sale Asphalt Distributor Factory PriceUS$ 22,000 - 30,000MOQ: 1 Set
-
Asphalt Distributor Truck With Function and Operator Advice for UsesNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
ICOM
Model Number
ZM-8SPSZ
After-sales Service Provided
Engineers available to service machinery overseas
Parameter
BITUMEN SPRAYER
Model | ZM-8SPSZ |
Overall size (mm) | 6600×2280×1960 |
Complete weight (kg) | 4650 |
Tank size (mm) | 3800×2020×1680 |
Tank volume (L) | 8000 |
Engine model | YANMAR 3TNV82A-SNN |
Power (kw/r/min) | 15.3/2200 |
Hydraulic pump | CBQL-F525/F525-CFH-R |
Burner | G20 |
Burner power (kw) | 95-216 |
Volume of hydraulic oil tank (L) | 150 |
Air compressor | V-0.12/8 |
Asphalt pump | QGB450 |
Asphalt pump motor | LY-A2F107W2P2 |
Heat transfer oil pump | 40-25-160 |
Heat transfer oil pump | A2F16W6.1P3 |
Multi-way valve | ZS1-L20E-W-OO |
Lift cylinder | HSGL01-63/45E-3101 |
Spray width (m) | 2-5 |
Spray rate (L/m2) | 0.25-3.0 |
Width of spray tube (m) | 5 |
Number of nozzles (pc) | 33 |
Nozzle type | Fan-shaped |
Allowable viscosity of working medium (Cst) | ≤300 |
Max. air pressure of cleaning system (MPa) | 0.6 |
Max. air pressure of hydraulic system (MPa) | 20 |
