Brief introduction
1.It's a kind of newly developed automatic tablet press machine.
2.It can press granular,powder-like material into a variety of general and special-shaped pieces.
3.It is suitable for the products which is required high-desity.
4.Easy to learn moudle replacement and installation.
5.High degree of automation.
6.All actions by the micro computer PLC control.
7.Can be properly adjust the pressure and thickness of the product.
8.Offer molding manufacturing service.
9.We'll arrange technician to your factory to help you bebug the machine and train your works how to use it.
10.Warranty period: One year (We'll provide vulnerable parts and service door to door by free within one year)
11.Appearance:Stainless Steel
Hydraulic System:
1.Imported form Taiwan CE Marking PLC(Mitsubishi)
2.With high stability
3.Avoid oil leaking and polluting
4.Ensure the pressure enough and action synchronized for continous.
5.Oil cylinder woring area and mechanical working area are independent of each other
6.Non-polluting and automatic heated.
Main technical parameters
Model |
SYST-45 |
SYST-100 |
SYST-200 |
SYST-500 |
Maximum Working pressure |
45T |
100T |
200T |
500T |
Uprush max stroke |
150mm |
200mm |
200mm |
200mm |
Max. Depth of fill |
150mm |
180mm |
200mm |
200mm |
Max diameter of lower mould |
300mm |
300mm |
300mm |
300mm |
Max diameter of products |
200mm |
200mm |
200mm |
200mm |
Capacity |
3-4 times per minute |
3-4 times per minute |
3-4 times per minute |
1.5-2 times per minute |
Motor power |
7.5kw |
11kw |
15kw |
11kw+3kw |
Dimension |
1.8*1.5*2.5M |
1.8*1.6*2.6M |
2.3*1.6*3.2M |
3.6*2.2*3.8M |
Weight |
2300kg |
3500kg |
4500kg |
12000kg |
Our Service
Pre-sale Service
We provide professional consultation about each type of machine,and offer free testing service to help customers purchase suitable machine.Customers are also welcomed to visit and evaluate our factory.
After-sale Service
After customers received tablet press machine, we will arrange our technician go to your factory to help you instal and debug the machine,also provide technical training for your workers.
Package&Shipping
1.SYST-16 to SYST-200 The machine will be packaged by wooden case
2.SYST-300 to SYST-1500 The machine will be loaded in the container with waterproof
3.All the machines will be adjusted and tasted before shipping
Applications
Agriculture: Feed block, fertilizer tablets, animal food, animal salt lick
Electronics Batteries: thermistor, integrated circuit components, carboniferous brush films, quick drop-off
Health Products: calcium, propolis tablets, effervescent tablets, bath salts tablets
Chemical: disinfection tablets, insect repellent films, camphor ball, detergents, fragrances, catalysts, metallurgy powder, glass powder, ceramic powder products, art powder, sand round block, magnetic materials.
To press heavy block like animal salt block, licks, we need larger pressure, below rules are for your reference:
A. We would like to recommend machines based on your requirements as belows:
1. Products
2. Products' size and shape
3. Products' weight
4. Capacity
B. We can design, customize and make dies for customers
Detail Parts:
Our Customers:
RFQ
- Delivery date
We will arrange the production and shipment as soon as we received the deposit,and update the information with customers timely.
- Terms of payment
we can accept the payment by T/T or Western Union or Cash.For T/T,the customer can choose 100% in advance or 30% in advance,and pay the 70% balance before shipment.
- After -sale service
For most of the machines,the warranty will be one year since the date of shipment,we supply the on-line service for all the customers,and also supply the spare parts all the time with cost price,for some complicate machine or part,we can send our technicians overseas to help debug too.
- How do you guarantee I can receive ordered goods after payment?
We are a legally established company supervised by the government,and is registered in customs of China and China Chamber of International Commerce.Besides,we are the member of Alibaba and has been checked by the third part as the real and legal company,So,please rest assured.What is more,honesty and trustworthiness is our basic principle and company motor.
- How to make an order?
Step 1.Please tell us your material characteristic and the diameter&height you require
Step 2.Then we will make a solution for you to confirm the order details
Step 3.You can send us some material to test,or you can visit our factory
Step 4.Finally,make a deal and we will deliver the goods with the stipulated time
CE Certification
