Help CenterQ3110BII Series Top Quality Continuous and Reliable Rolling Drum Type Shot Blasting Machine and Wear Parts
Related Products
-
Q37 Series Price Favorable Hanger Type Shot Blasting Machine China Supplier Hot SaleUS$ 5,800 - 6,500MOQ: 1 Set -
QR3210 Automatic Loading System Tumble Belt Shot Blast Cleaning MachineUS$ 22,000 - 26,000MOQ: 1 Set
-
Catenary Stepping Overhead Conveyor Chain Shot Blasting Machine by China Supplier OfferUS$ 45,600 - 46,650MOQ: 1 Set
-
QH900 Gas Cyliner Shot Blasting MachineUS$ 23,000 - 28,000MOQ: 1 Set
-
Q38/Q48 Series Continuous Overhead Conveyor Chain Shot Blast Cleaning Machine for Rust Cleaning by China Machine ManufacturersUS$ 45,600 - 46,650MOQ: 1 Set
Q31 Series Small Metal Parts Rolling Drum Shot Blaster
The machine is suitable for surface rust removal of work pieces in medium or small quantity batch production with many v
arieties.Put the work pieces into the barrel and blasting it in side way.
The high-speed impeller throws the abrasive to the continuous tumbling castings or forgings in barrel, to remove the
greensand or scaleson the surface. It cleans evenly and its productivity is high, so it is suitable for cleaning the small work
pieces whose weight are under 15g in medium or small-scale casting or forging workshops.
specification
Serial number | Type Item | Q3113BI | Q3113BII | Q3110BI | Q3110BII | |
1 | Diameter of rolling drum | mm | Φ1300 | Φ1300 | Φ1000 | Φ1000 |
2 | Loading capacity | kg | 600 | 600 | 300 | 300 |
3 | Productivity | kg/h | 2500-3500 | 2500-3500 | 600-1500 | 600-1500 |
4 | Power(excluding dedusting) | Kw | 14.5 | 16.3 | 9.7 | 11.9 |
5 | Maximum weight of workpiece | kg | 30 | 30 | 15 | 15 |
6 | Rotational speed of rolling drum | r/min | 2.5 | 2.5 | 3 | 3 |
7 | Abrasive flow rate | kg/min | 160 | 160 | 120 | 120 |
8 | Ventilation capacity | m3/h | 2000 | 2800 | 800 | 2000 |
9 | Dedusting efficiency | % | 85 | 99 | 85 | 99 |
10 | Outline dimensions | mm | 2550*2341*2250 | 4362*2341*2250 | 2078*2458*1861 | 3870*2458*3370 |
casting iron base
not weldment
we have two type of material for drum liner:
special casting iron liner wear resistant rubber liner
drum type blast liner
Q3110BII
dust ventilation rate 2000CBM/Hr Dust collector
