Structure:
Main body of the machine, electric box. Bowl Cutter adopted excellent quality stainless steel; knife material is
made by special treatment.
Control:
Control system of the machine includes a control panel with function keys.
Application: For all kinds of meat, vegetables and fish processing.
Feature:
1. Reasonable knife assemble makes the products in high degree of fineness, small heating. It is one of the
most necessary machines in meat processing.
2. Material of the bowl is cast stainless steel, treated in special way.
3. Imported bearings, special sealing types which greatly guarantee endurance of bearings.
4. Powder feed-in hole, products output automatically.
5. There is water blow-off valve in the bowl, 3°leaning, after cleaning water will not stay in the bowl.
Model | ZB-40 | ZB-80 | ZB-125 |
Capacity(kg/) | 15-20 | 30-40 | 60-70 |
Volume(L) | 40 | 80 | 125 |
Power(kw) | 6.6 | 13.97 | 39.97 |
Knives(pieces) | 3 | 6 | 6 |
Shaft speed(rpm) | 1500/3000 | 200/1500/3000 | 126/1800/3600 |
Bowl Speed(rpm) | 11/17 | 11/17 | 8/12 |
Unloader Disc Speed(rpm) | - | 83 | 83 |
External dimension(mm) | 1060*900*1300 | 1960*1170*1240 | 2400*1420*1300 |
Installation Dimension(mm) | 1500*1500*2000 | 2500*2000*2000 | 3000*2000*2000 |
Weight (kg) | ≈600 | ≈1200 | ≈1380 |
ZB40
ZB80
ZB125
1.Pre-sale services
We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.
2.Sale services
Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
3.After-sale services
To establish long term friendship, we will regularly pay return visit to customers.
Supplying technique, building design, instruction, installation and debugging for free.
