HD Series Multi Directional Movement Mixer is a novel materials mixing machine widely applicable to industries such as pharmaceutical, chemical, foodstuff and light industry as well as R & D. Institutes. The machine can perform a very uniform mixing of powder or granular material with a good mobility.
1. Because the mixing barrel in multiple directions, there is no centrifugal force acting on the material.
2. As well as no phenomena of gravity segregation, delamination and accumulation of materials.
3. The mixing rate can be up to 98 percent for the materials with big difference in terms of specific gravity. Therefore, it is an ideal product currently compared with other various mixers.
4. The barrel has high loading rate max.80 percent, so that it features high efficient and short mixing time.
5. The barrel transitional radius everywhere, which has been super finished.
| Model | HD5 | HD10 | HD15 | HD50 | HD100 | HD200 | HD400 | HD600 | HD800 | HD1000 |
| Barrel capacity (L) | 5 | 10 | 15 | 50 | 100 | 200 | 400 | 600 | 800 | 1000 |
| Max loading capacity (L) | 4 | 8 | 12 | 40 | 80 | 160 | 320 | 480 | 640 | 800 |
| Max loading weight (KG) | 2 | 4 | 6 | 20 | 40 | 80 | 160 | 240 | 320 | 400 |
| Speed of driving shaft (R/MIN) | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 |
| Motor power (KW) | 0.25 | 0.37 | 0.37 | 1.1 | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 7.5 |
| Overall dimensions (MM) | 600*10 00*1000 | 650*10 00*800 | 700*10 00*1000 | 1000*14 00*1200 | 1200*17 00*1500 | 1400*18 00*1600 | 1800*21 00*1950 | 1900*23 00*2250 | 2200*24 00*2300 | 2250*26 00*2600 |
| Total weight (KG) | 150 | 180 | 200 | 300 | 500 | 800 | 1200 | 1500 | 2000 | 2500 |
Pre-Sales Service: After-Sales Service:
* Inquiry and consulting support. * Advisory service: Users encounter any problems in the use process, can call the company for technical support.
* Sample testing support. * Warranty: Warranty period of the product, if quality
* View our Factory. problems, the company is responsible for the warranty service.
