Home > Products > Ribbon mixer > 2015 new hot fashion hotsale guangzhou vacuum mixer emulsifier
2015 new hot fashion hotsale guangzhou vacuum mixer emulsifier
- 50 Unit / Units per Month
- shanghai port
- Scented teatriangle package packaging machine Inside and outside bag packaging line
- Give bag packaging machine Between-meal nibblespackaging line
- Internal and external package linkage line Green teatriangle package packaging machine
- Triangle package packaging machine Green teapackaging linkage line
- Between-meal nibblesgive bag packaging machine The five metalsbag packing machine
- Black teatriangle package packaging machine Packaging linkage line
Product Details
Condition: | New | Application: | Beverage, Chemical, Food | Packaging Type: | Case |
Packaging Material: | Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 380V (can be customized) | Power: | 5.5kw(can be customized) | Place of Origin: | Shanghai, China |
Brand Name: | tandy | Model Number: | TDL-500 | Dimension(L*W*H): | please contact with seller |
Weight: | base on the machine type | Certification: | GMP/CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
2015 new hot fashion hotsale guangzhou vacuum mixer emulsifier
Features of guangzhou vacuum mixer emulsifier:
TDL horizontal ribbon mixer is used for application to, power and power; granule and granule; powder and a few liquid mixing; it is widely used in food, chemical industry, pharmaceutics, feedstuff, plastic, building material and so on; Customizing according to client’s specific requirement, it can be from 304,316L,321 and carbon steel etc. it can be according to GMP standard, too.
1. wide application for mixing material, for paste mixing even; keep granule mixing intact.
2. material proportion different 1:1000 ~10000 perfectly mixing;
3. Customizing according to client’s requirement such as hotting Cooling, pression, vacuum ect.
Reference paramete of guangzhou vacuum mixer emulsifier:
Type | Volume(L) | Coefficient | Power(KW) | Rotate speed(R/min) | Size(mm) | Weight |
TDL-200 | 200 | 0.4-0.6 | 4 | 53 | 2020X630X1700 | 300 |
TDL-300 | 300 | 0.4-0.6 | 5.5 | 53 | 2300X700X1780 | 420 |
TDL-500 | 500 | 0.4-0.6 | 7.5 | 45 | 2600X840X1850 | 600 |
TDL-1000 | 1000 | 0.4-0.6 | 11 | 45 | 2930X990X2000 | 880 |
TDL-1500 | 1500 | 0.4-0.6 | 15 | 39 | 3280X1070X2150 | 1260 |
TDL-2000 | 2000 | 0.4-0.6 | 18.5 | 39 | 3620X1180X2320 | 1750 |
If you need more technical parameters, please contact us. |
Picture of guangzhou vacuum mixer emulsifier:
Principle of working:
TDL horizontal ribbon mixer consists of a mixing storage, helix blades and transmission parts. There is two tiers or three tiers of ribbon blender axis in the mixing container. The principle of working as below:
1.The outer helix will move the material from its two sides to the central part,
2. The inner helix will transfer the material to the two sides, performing convection mixing.
3. There is discharge exit on the centre of the u container bottom of mixer; The outer helix match with main helix make the materials to center exit discharging; it make u container no leftover in u container.
Our factory:
Our Exhibition:
guangzhou vacuum mixer emulsifier
