45kw 60hp 5t-6t/h wood chips grinding machine for mushroom cultivation
Description
The basic principle is straightforward. A wood chips grinding machine is essentially a steel drum containing a vertical or horizontal rotating shaft or drum on which hammers are mounted.
The hammers are free to swing on the ends of the cross, or fixed to the central rotor. The rotor is spun at a high speed inside the drum while material is fed into a feed hopper. Wood chipsis impacted by the hammer bars and is thereby shredded and expelled through screens in the drum of a selected size.
Features
1.Compact design with high production efficiency, easy operation and maintenance;
2.Quenched manganese steel hammers with hardness HRC56-62 ,shows excellent wear-resistance;
3.Upper and lower housing made from cast iron or carbon steel for long service life;
4.Different mesh screens available
5.Electric motor or engine powered
6.Dual cyclone dust collector
casted Upper and lower hammer mill housing
Application
45kw 60hp wood chips grinding machine is widely uesd in industrial power plant, commercial paper mill, individual mushroom farmer, housing heating, and many industries
1. Biofuels
After Crushing wood chips into powder, it can be pelletized by a pellet mill, also called pellet press .This kind of wood pellets is featured with flexible storage and transportation, and most important, it's more environmentally friendly and without waste gas when burning
2. Mushroom cultivation
Sawdusts is critical to mushroom cultivition. By simply changing screen sieve, you can get desired mesh of wood dusts
3.Paper mill
Why PTO hammer mill?
A power take-off (PTO) is any of several methods for taking power from a power source, such as a running engine, and transmitting it to an application such as an attached implement or separate machines.
Voltage in countries differ from one another, or not accessible for some regions. 9FQ50-80 wood chips grinding machine can be driven by a 45kw electric motor or an 60hp engine for your choice.
Particle Size Refference
Parameter
Description: 9FQ-50-80 wood chips grinding machine
Weight: 1T
Size: 2500*2400*2700mm
Hammer Qty: 48 pcs
Grinding Chamber Width: 800mm
Rotor Dia.: 500mm
Speed: 3400 rpm
Power: 45kw or 60hp
Output: 5-6t/h
