Aluminum Foil Pan Forming Machine Brand Product
US$ 1,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Ungar
Model Number:
C-type 63 Ton press
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Aluminum Container Making Machine PressUS$ 1,000 - 100,000MOQ: 1 Set -
Aluminium Foil Container Making Machines Vertical Press Machine(UN-55T) 550KN C-Type Automatic Press Production LineUS$ 10,000 - 100,000MOQ: 1 Set
-
Aluminium Foil Container Making Machine Vertical Press Machine (UN-80T) 800KN H-Type Automatic Press Container Production LineUS$ 10,000 - 100,000MOQ: 1 Set
-
Aluminium Foil Container Making Machine Vertical Press Machine(UN-63T) 630KN C-Type Automatic PressUS$ 10,000 - 100,000MOQ: 1 Set
-
Love Aluminium Foil Container Making Machine Vertical Press Machine (UN-80T) 800KN H-Type Automatic PressUS$ 10,000 - 100,000MOQ: 1 Set
Place of Origin
Shanghai, China
Brand Name
Ungar
Model Number
C-type 63 Ton press
After-sales Service Provided
Engineers available to service machinery overseas
Aluminum Foil Pan Forming Machine
Product description:
The Press which offers a large tool area is optimized for fast mould change and easy setup. The shut height is adjustable according to the mould requirement. The Press has 12PLC controlled solenoid valves with independent pressure redulators for optimal tool setup and adjustment. The press is also equipped with 4 additional pressure tanks for optimal air distribution.
The operator of the machine only has to set up the packaging requirement(pcs to count)at the touch screen and collect the finished counted and stached products on the end of the line.
The operator of the machine only has to set up the packaging requirement(pcs to count)at the touch screen and collect the finished counted and stached products on the end of the line.
| Nominal force | 630KN,C-Type Press |
| Stroke time | 20-70 times/ Min. |
| Slide block stroke(Optional Size ) | 200/220/240/260mm(Option) |
| Max.height of mould installation | 420/450mm |
| Height adjustment for mould | 80mm |
| Distance from slide block center to body | 550mm |
| Adjustable work block dimension X2 | 1000(L)x200(W)x300(H)mm x2 |
| Dimension of Slide block bottom surface | 360x480mm |
| Hole Dimension Slide block bottom surface | 320-325x380mm |
| Size of centering hole(Diameter×Depth) | Φ60x80mm |
| Press Machine Type | Electric shut hight adjustment |
| Press Net Weight | 8,000KG |
| Voltage &Frequency(Optional) | 380V - 50/60Hz - 3 Phase |
| Total power | 11kW |
| Press dimension (LxWxH) | 2200x1300x3600mm |
Advanages:
1. Welded body with steel plate and high intensity.
2. Main motor is made by Siemens.
3. Adopts combined pneumatic friction clutch and brake.
4. Cluster gear adopts the flooding oil lubrication.
5. Six-face rectangle lengthen guide;
6. Equipped with hydraulic overload protecting device.
7. Electric shut height adjustment with digital display.
8. Equipped with lifting balance cylinder.
9. Duplex valves imported.
10. Electric compelling grease lubrication system.
11. Balancing cylinder adopts manual lubrication system.
12. One set of blowing device.
2. Main motor is made by Siemens.
3. Adopts combined pneumatic friction clutch and brake.
4. Cluster gear adopts the flooding oil lubrication.
5. Six-face rectangle lengthen guide;
6. Equipped with hydraulic overload protecting device.
7. Electric shut height adjustment with digital display.
8. Equipped with lifting balance cylinder.
9. Duplex valves imported.
10. Electric compelling grease lubrication system.
11. Balancing cylinder adopts manual lubrication system.
12. One set of blowing device.
Product pictures:
Company information:
UNGAR Machinery (Shanghai) Co., Ltd is an Austrian enterprise established in 2009, supplying high productive multi-cavity moulds and machines, which includes press, stacker, package, re-winder, paper lid cutting, decoiler, scrap press and additional equipments.
UNGAR complete integrated production line has been specially designed and developed for the production of aluminum foil food container, plate and household foil rolls.
UNGAR Machinery (Shanghai) Co., Ltd also offer customized service for technical optimization, mould prove, machine installation, material test, training course, telephone assistance and so on.
