Home > Manufacturing & Processing Machinery > Mould > Plastic Mould > Autopack Paper Lid Machine

Autopack Paper Lid Machine

Name: Autopack Paper Lid Machine
Brand: Ungar
SKU: 141262124
Availability: InStock

US$ 1,000 - 50,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

Ungar

Model Number:

Ungar 4 way stacker

Contact Supplier Request Quote Chat Now

Ungar Machinery (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name Ungar

Model Number Ungar 4 way stacker

After-sales Service Provided Engineers available to service machinery overseas

Autopack Paper Lid Machine

Product description:

The stacker is an electro pneumatic machine commanded by a PLC that provides to stack the trays and containers out from the press and to load them stacked in columns.

It is controllable according to the demands of the cycle of production through an operative panel.

Advantages:

1. Desing for labor saving and production efficiency.
2. Stack trays and containers of different dimensions.
3. Easy to operate and adjust based on customize requirements.

Auto container stacker Model:The UN-6010 is for 55Ton/63Ton/80Ton/110Ton,with 1 to 5 lanes
Collector belt width	600mm(45ton)/850mm(63ton)/1080mm(80ton)/1340mm(110ton)
Collector belt heihgt	1100+-100mm (According press machine's size, we will adjustable height system on requested)
Min. container dimensions	80 x 120mm(Smaller on request)
Container dimensions	450 x 340mm(1 lane) 230 x 340mm(2 Lines) The lanes could be less or more on your condition, also depend on container shape.
Max. height of container stack	300mm(Depend on the container shape and size)
Lifting system	By step motor and linear guide
Photocell electronic counting device	Container counter automatically stops press at top of stroke in emergency situations.
Control panel	Touch screen panel
Stacking system	Photo electric sensor controls the height of the stack with electric brake system.
Installed Power	1Kw
Air consumption(2lanes)	0.1m³/Min
Net.weight	300kg
Stacker dimensions(LWH)	55ton:3200x1050x1400(+-100mm)mm; 63ton:3200x1300x1400mm; 80ton:3200x1530x1400mm; 110ton:3200x1790x1400mm
Notice:The Stackers specifications depend on container size and shape and the mould cavities.

Company information:

UNGAR Machinery (Shanghai) Co., Ltd is an Austrian enterprise established in 2009, supplying high productive multi-cavity moulds and machines, which includes press, stacker, package, re-winder, paper lid cutting, decoiler, scrap press and additional equipments.

UNGAR complete integrated production line has been specially designed and developed for the production of aluminum foil food container, plate and household foil rolls.

UNGAR Machinery (Shanghai) Co., Ltd also offer customized service for technical optimization, mould prove, machine installation, material test, training course, telephone assistance and so on.
