Application of the wood hammer mill
1.Suitable for crushing wood branch, shavings and chips etc.
2.The wood hammer mill shell is welded by steel plate, the site in the crush room which touches with the materials all using the wearable and commutative parts and double wear plate.
3.The motor and rotor are installed in the same heavy-duty base using coupling direct drive,the rotor are checked by dynamic balance, and can work forward and reverse, the hammers are arranged symmetrically.
4.Belt driving, low noisy and low temperature for bearing.
5.Raw material size for inlet: less than 100x50x20mm.
6.Finish size: less than 8mm.
High Quality Design wood hammer mill
1.)I promise to provide a high quality product at a fair price that will last for years and years, shipped as quickly as possible along with professional engineers support you require to get you up and running.
2.)All the parts of products are rechecked before transportation, therefore the clients will receive the best quality products..
3.)Free consulting service, please contact us when you have any questions about biomass pellet machinery.
4.)1 Year Warranty on all parts.
Technology parameters of wood hammer mill
Model | DLFS600F | DLFS800F | DLFS1000F |
Blades number | 24pcs | 32pcs | 36pcs |
Feeding port size | 400x240mm | 500x300mm | 600x350mm |
Main shaft rotary speed | 2900rpm | ||
Motor Power | 15-18.5kw | 22-30kw | 37-45kw |
Working capacity | 100kg/h | 150-200kg/h | 200-300kg/h |
Weight | 820kg | 1500kg | 2300kg |
Why buy from us
Dongding company is one of the largest manufacturer of pellet stove, wood crusher and pellet making machine in China. That is why we can offer you brand new products at extremely low prices.
We are the experts of biomass fuel machinery field, there is a professional team of designing and manufacturing in our factory. All the material and process are controlled strictly, that our products have a unique cost performance.
The kind of packing will be decided by our clients, or you can leave it to us. Whatever which one is used, all the good will be packed carefully by our professional workers to ensure the safety of your shipment.
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding Heavy Industry Equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technology professional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply Vacuum dryer,rotary dryer, wood pellet machine, biomass pellet machine, coal gasifier,sawdust burner,wood/biomass pellet burner, wood/biomass prowder burner,biomass gasifier,wood chipper,wood hammer mill and other machine.
