1. Functions of wood chips hammer mill:
wood chips hammer mill can grind all kinds of materials of pellet feed, such as corn, sorghum, grain, legumes, broken cake pellet and others.
wood chips hammer mill is widely used for grinding for paper, wood chips, rice bran, rice straw, vine, maize straw, sorghum stalk, beanstalk, wheat straw etc.
wood chips hammer mill is mainly used in wood factory, feed factory, cultivation factory, Chemical industry and so on.
2. Introduction of wood chips hammer mill:
The crushing fineness is determined by screen aperture size. The crusher, fan, cyclone and dust removal equipment compose of grinding system and reduced the dust.
Wood boards crusher machine has hammers inside, when the speed reaches a certain degree, the extent of damage to the corn straw, wood, branches increases. Hammers are an indispensable equipment in the wood processing program.
3. Advantages of wood chips hammer mill:
1.) wood chips hammer mill feed automatically: convenient operation, high production efficiency.
2.) Work smoothly: drum, continuous, and the dynamic balance processing, safe and reliable.
3.) Durable: steel structure components, solid and reliable materials, USES the high power self-aligning bearing, long service life.
4. )Low cost, small power; Good cutter selection, double blade, service life can reach within
500 to 1000 hours, and can be repeated resharpening.
5.) Easy to move on: according to customer demand production trailer mobile crusher,it is convenient for the field production.
4. Main structure of wood chips hammer mill:
wood chips hammer mill is made up of the base, rotor, fan and upper cover. Materials fall into the crushing room through feed inlet. Ther are crushed under the action of high speed rotating hammer blowing and screener friction, go through the screener hole and discharge from the outlet unser the action of centrifugal force and flow.
Technology parameters of wood chips hammer mill
Name |
Large sawdust making machine |
Model |
DLFS1500 |
Input size |
1500×400mm |
Knife quantity |
60pcs |
Knife roller rotary speed |
2400r/min |
Finish chips |
3-30mm |
capacity |
5-8t/h |
Host Motor power |
55kwX2 |
Weight |
5500kg |
Outside dimension |
3150*3250*3350mm |
Feeding conveyor |
Length:8000mm Width:1000mm Power:7.5kw |
Electric cabinet |
|
Box-type dust collector |
|
Standard equipped pipes |
|
Discharge conveyor |
Host machine with screw discharge conveyor |
Packaging of wood hammer mill
All our wood hammer mill are packaged by wooden box or according to your requirement.The big quanitity order will use container to delivery.
Shipping of wood hammer mill
All wood hammer mill are shipped after we product well and get all the payment.
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding Heavy Industry Equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technology professional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply Vacuum dryer,rotary dryer, wood pellet machine, biomass pellet machine, coal gasifier,sawdust burner,wood/biomass pellet burner, wood/biomass prowder burner,biomass gasifier,wood chipper,wood hammer mill and other machine.
Pre-sales Service:
1. The wide product range enables us to provide our customers with stand-alone machines or complete processing plants;
2. Based on our customers' request and budget, our experts make efficient, reliable solutions;
3. Before placing the order every customer has the chance to visit working machines or complete plant in the site;
4. We have a full set of testing equipment, to provide a good test environment.
After-sales Service:
1. Experienced technicians guidance and engineers will be dispatched to the quarry site to help install the customers' plants;
2. Provide necessary training about machine daily maintenance to local workers ;
3. After-sales department has well-trained employees and professional installation engineers.
