Help Center2017 Competitive Price Wood Crusher Hammer Mill With Good Quality
Related Products
-
400 Kg/h Wood Crushing Machine / Sawdust Making Machine for SaleUS$ 6,500 - 8,000MOQ: 1 Set -
High Efficiency Wood Chip Crusher/wood Sawdust Hammer Mill for Big Forest FarmUS$ 8,000 - 8,000MOQ: 1 Set
-
Wood Crusher Machine for Making Sawdust/wood Straw CrusherUS$ 5,000 - 5,000MOQ: 1 Set
-
CE Approved Wood Crusher Straw Hammer Mill for SaleUS$ 8,000 - 8,000MOQ: 1 Set
-
CE&ISO Approved Wood Hammer Mill for SaleUS$ 5,000 - 5,000MOQ: 1 Set
Introduction of wood crusher hammer mill
1. Unique Feeding Design, the feeding inlet is made at the side of the device to make feeding easily.
2.The shell is welded by steel plate, the site in the crush room which connects to the materials all use the wearable and commutative parts and double wear plate.
3.The motor and rotor are installed in the same heavy-duty base, using coupling direct drive, the rotor are checked by dynamic balance, and can work forward and reverse, the hammers are arranged symmetrically.
4.The second grinding designed for grinding chamber, the output can increase 15% even particle size.
5.Two kinds of gap between beaters and screen through changing position of beater are used for coarse and fine grinding.
6.The smaller gap between beater and screen can be used for grinding coarse and fine materials.
7.Applicable for raw materials grinding such as corn, Chinese sorghum, wheat, crumbled cake-shaped material etc.
8. It can also grind the raw materials: wood chips, straw, EFB, rice husk, grass, sunflower, grass, wood chips, wood shaving, olive slag, paper etc
The raw material and final product of wood crusher hammer mill
Features of wood crusher hammer mill
1. The shell is welded by steel plate, the site in the crush room which connects to the materials all use the wearable and commutative parts and double wear plate.
2. The second grinding designed for grinding chamber, the output can increase 15% even particle size.
3. Applicable for raw materials grinding such as corn, Chinese sorghum, wheat, crumbled cake-shaped material etc.
4. It can also grind the raw materials: wood chips, straw, EFB, rice husk, grass, sunflower, grass, wood chips, wood shaving, olive slag, paper etc.
Technology parameters of wood crusher hammer mill
|
Model |
Motor Power( kw) |
Speed(r/min) |
Capacity( kg) |
Product size(mm) |
Weight(kg) |
DMF-500 |
7.5 kw |
3200 |
300-1000 |
1300x600x800 |
320 |
DMF-600 |
15 kw |
2800 |
500-1500 |
1600x800x000 |
560 |
DMF-700 |
22kw |
2400 |
800-1800 |
1800x1000x1900 |
680 |
DMF-800 |
30 kw |
2000 |
1200-2000 |
1800x1150x1350 |
980 |
Packaging of wood crusher hammer mill
All our wood crusher hammer mill are packaged by wooden box or according to your requirement.The big quanitity order will use container to delivery.
Shipping of wood crusher hammer mill
All wood crusher hammer mill are shipped after we product well and get all the payment.
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding Heavy Industry Equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technology professional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply Vacuum dryer,rotary dryer, wood pellet machine, biomass pellet machine, coal gasifier,sawdust burner,wood/biomass pellet burner, wood/biomass prowder burner,biomass gasifier,wood chipper,wood hammer mill and other machine.
