Biomass energy is a clean energy, but the premise is biomass combustion situation. In the case of biomass combustion, the combustion products mainly carbon dioxide, water vapor and dust, its emissions of sulphur oxides, similar to natural gas; And biomass is a renewable energy, for global carbon emissions to zero.
But the biomass direct combustion does not guarantee its can complete combustion, so when to biomass particles as a fuel, the current methods is the use of biomass particles combustion machine, make the secondary combustion biomass particles, so as to achieve complete combustion effect.
Secondary combustioncan increase heat loss, lower thermal efficiency; Especially when using water cooling way of furnace body cooling, a lot of heat being taken away by cooling water. HQL burning biomass granule machine, the air duct inside the furnace, a secondary to the wind, and the improvements to the wind fan and perfect, on the basis of making using air cooling mode of the surface of the furnace temperature is not higher than other brand USES the water surface of the furnace body temperature, the improvement of the secondary air,
also greatly reduce or even eliminate the phenomenon of coking.
Features of biomass pellet burner:
1. A unique, independent research and development of secondary air duct design and configuration of a dedicated
fan, this biomass pellet burner not only burning effect is good, and the combustion engine air cooled water cooling effect, so as to avoid the
additional loss of heat, the thermal efficiency of biomass particles combustion machine so our company in the
market of similar products in a leading position;
2. Reasonable a secondary to the wind can make grate fully cooling, so as to avoid the common grate coking phenomenon;
3. Large bunker and unique way of feeding, make my company's combustion machine, the only has not only large and warehouse face below the eye sight of biomass particles bin, the bin is not
only convenient observation, feeding more convenient;
4. The super thick layer high aluminum refractory material casting, with good air cooling way,
make my company production of biomass gasification combustion machine service life of
the furnace body in the leading position among the similar products;
5. Automatic control system of delay shutdown function, let use is more convenient and safer.
The wood pellet burner used to biolier
Item model | Feeding conveyor motor power(kw) | Motor power of feeder(kw) | Air fan power(fan) |
DL-LK1.0 | 1.1 | 1.1 | 2.2 |
Size of main burner(mm) | Sawdust consumption (kg/h) | Natural gas consumption (Nm3/h) | Heating valve (kcal/h) |
2400X2200X1550 | 155 | 75 | 600,000 |
The technical data of wood lpellet burner;
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding heavy equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technologyprofessional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply rotary dryer, wood pellet machine, biomass pellet machine, coal gasifier,sawdust burner,wood/biomass pellet burner, wood/biomass prowder burner,biomass gasifier,wood chipper,wood hammer mill and other machine.
Export standard container 20GP OR 40GP,40HQ,FR container,In bulk,the spare parts in wooden case.
Guarantee And after-sale services:
A: one year guarantee for whole machine
B: 24 hours technical support by email
C: Calling or door-to-door service
D: Use-friendly English software, user manual and detailed video/CD
1) What's the use life of your biomass burner?
My answer: 10 years if you operate obey our operation manual
2)What’s the consumption per hour of your burner?
My answer: This is comply with the model you choose, details pls check section 4.
3) Which material do you use?
My answer: New high-temperature composite materials, like refractory bricks, castable material. durable for use.
4) What’s your combustion principle?
My answer: Suspension combustion, half fuel half air, burn furthest can up to 95% or more.
5) How about the ignition system?
My answer: Automtic system, diesel & petrol either is ok.
6) How much time it takes to start the burner?
My answer: About 10-20 minutes.
7) How much time it takes to install the machine?
My answer: It's easy for our technicians, it depends on the equipment that you need.
8) How many sawdust it needs?
My answer: Depends on the model you choose, details will send you by email.
