Application scope of biomass pellet burner
Biomass pellet burner wide application scopes: Suitable for steam boiler,
fuel oil, gas, coal boiler, various kinds of organic spray drying equipment, large-scale farming factories, cereal and food drying, tobacco drying, various kinds of large, medium, small workshops, greenhouse heating and etc.
1,burner mouth :connect with boiler or dryer. according to the size of your boiler, then design the burner mouth for you.
2,water inlet. Cool water can enter into the water inter layer from here.
This is water cooling system, thus can reduce the temperature of burner.
3,water outlet.hot water can be come out from the water outlet.
4,air increasing fan, there are two air increasing fans in it. One of them for burner mouth, and anther one is for bottom of burner. for sufficient burning.
5,igniting hole, for ignite the biomass burner automaticly.,
6,ash discharge hole , for cleaning some times.
7,view hole, we can watch the flame situation the fire of burn.
8,feed inlet connect with pipe, so the material be entered into from here.
The pellet material of biomass pellet burner
Full Automatic Biomass Burner for Boiler Features: Biomass Burner for Boiler 1.Multi-level interlock protections like water level, steam pressure, gas pressure and so on
2.High efficient thermal insulating material, low boiler surface temperature.
3.All components like burner, pump, water level gauge, valves are limited to choose renowned brands
Detail parts of biomass pellet burner
Features of the biomass wood pellets burner/ sawdust burner for boiler :
The wood pellet burner used to biolier
The hot selling biomass pellet burner testing in our factory
Item model | Feeding conveyor motor power(kw) | Motor power of feeder(kw) | Air fan power(fan) |
DL-LK1.0 | 1.1 | 1.1 | 2.2 |
Size of main burner(mm) | Sawdust consumption (kg/h) | Natural gas consumption (Nm3/h) | Heating valve (kcal/h) |
2400X2200X1550 | 155 | 75 | 600,000 |
The technical data of wood lpellet burner;
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding heavy equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technologyprofessional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply rotary dryer, wood pellet machine, biomass pellet machine, coal gasifier,sawdust burner,wood/biomass pellet burner, wood/biomass prowder burner,biomass gasifier,wood chipper,wood hammer mill and other machine.
Export standard container 20GP OR 40GP,40HQ,FR container,In bulk,the spare parts in wooden case.
Guarantee And after-sale services:
A: one year guarantee for whole machine
B: 24 hours technical support by email
C: Calling or door-to-door service
D: Use-friendly English software, user manual and detailed video/CD
1) What's the use life of your biomass burner?
My answer: 10 years if you operate obey our operation manual
2)What’s the consumption per hour of your burner?
My answer: This is comply with the model you choose, details pls check section 4.
3) Which material do you use?
My answer: New high-temperature composite materials, like refractory bricks, castable material. durable for use.
4) What’s your combustion principle?
My answer: Suspension combustion, half fuel half air, burn furthest can up to 95% or more.
5) How about the ignition system?
My answer: Automtic system, diesel & petrol either is ok.
6) How much time it takes to start the burner?
My answer: About 10-20 minutes.
7) How much time it takes to install the machine?
My answer: It's easy for our technicians, it depends on the equipment that you need.
8) How many sawdust it needs?
My answer: Depends on the model you choose, details will send you by email.
