800 ton per day Low Energy Consumption Coal Slime Dryer Machine/Coal Powder Rotary Dryers low price supplier
coal slime dryer machine application range
coal slime dryer machine is developed on the basis of drum drying machine,this is new type professional special coal slime drying equipment.
coal slime dryer widely applied:
1. Coal industry, such as coal slime,raw coal,Flotation concentrate and other material’s drying.
2. The coal slime also can use to drying Construction industry blast furnace slag,clay,bentonite , lime stone and other material.
3. Also can used to drying ore dressing industry of various kinds of metal concentrates,slag,tailing and other materials.
4. The drying of none thermal sensitive material in chemical industry
coal slime dryer machine system working site 300 ton per day:
Characteristics of coal slime dryer machine:
coal slime dryer machine with a competitive price, , the advantage of professional coal slime drying machine:
1. coal slime dryer have a strong resistance to overload,large capacity,low fuel consumption, drying cost is very low.
2.Adopts downstream drying methods, hot air and wet material from the same side into the dryer machine,can take advantage of the high temperature hot air to obtain high evaporation strength,the material can reduce moisture in the short time.But the dryer outlet temperature is low,this is High thermal efficiency dryer machine
3.Another characteristics of coal slime drying equipmnent is can change operation parameters according to drying different materials. In the process of drying, the coal slime will form a curtain in the dryer body when the dryer machine working,make quality raw material with hot air heat exchange more fully, improve the efficiency of drying.
4.New type feeding equipment,outlet material equipment,eliminate the coal slime dryer feeding material jams, discontinuous and uneven and returns material, reduces the load of dust removal system;
coal slime dryer machine working site 1000 ton per day
The simple drawing of coal slime dryer machine system:
The technology Parameters of coal slime dryer machine:
Model |
Diameter (m) |
Length (m) |
speed |
Installation obliquity (%) |
Drying temperature (°c) |
Capacity (t/h) |
Motor (kw) |
Weight (ton) |
Φ1.8x18 |
1.8
|
18 |
3-6 |
3-5% |
≥800 |
5.0-5.5 |
18.5 |
30-35 |
Φ1.8x20 |
1.8
|
20 |
3-6 |
3-5% |
≥800 |
5.5 |
18.5 |
33-38 |
Φ2.2x20 |
2.2
|
20 |
3-6 |
3-5% |
≥800 |
6.5-7.0 |
22 |
56-60 |
Φ2.4x20 |
2.4
|
20 |
3-6 |
3-5% |
≥800 |
7.5-8 |
30 |
60-65 |
Φ2.5x20 |
2.5
|
20 |
3-5 |
3-5% |
≥800 |
8-9 |
30 |
63-68 |
Φ2.5x25 |
2.5
|
25 |
3-5 |
3-5% |
≥800 |
10-11 |
37 |
68-73 |
Φ2.8x20 |
2.8
|
20 |
3-5 |
3-5% |
≥800 |
13-15 |
45 |
75-80 |
Φ2.8x30 |
2.8
|
30 |
3-5 |
3-5% |
≥800 |
18-20 |
55 |
83-88 |
Φ3.0x20 |
3.0
|
20 |
3-5 |
3-5% |
≥800 |
18-20 |
55 |
78-85 |
Φ3.0x22 |
3.0
|
22 |
3-5 |
3-5% |
≥800 |
20-25 |
55 |
80-90 |
Φ3.0x30 |
3.0
|
30 |
3-5 |
3-5% |
≥800 |
25-28 |
75 |
90-100 |
Export standard container 20GP OR 40GP,40HQ,FR container,In bulk,the spare parts in wooden case.
Some case of our rotary dryer shipping to customer
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding Heavy Industry Equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technology professional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply machinery as below:
1.) Rotary dryer,lignite coal dryer, coal slime drying machine,Brewer grain dryer and other dryer
2.) Wood pellet machine, Biomass pellet machine, Animal feed pellet machine,Small pellet machine
3.)Coal gasifier,Biomass gasifier,MSW gasifier,Sawdust burner,wood pellet burner,biomass pellet burner, wood/biomass prowder burner and others
4.)wood chipper,wood hammer mill,wood crusher and other machine.
If you have any need of coal slime drying machine,lignite dryer,coal dryer and others, please contact with us.
