Simple Description of sawdust rotary dryer
New type sawdust rotary dryer is shaped as a horizontally inclined rotating cylinder. Wet sawdust is feed at feed port and discharged at the output port . In direct-type rotary dryer (cylinder drier), hot air move through the cylinder in direct contact
with the material in the dryer, either downstream or against the direction of its flow. The sawdust rotary dryer is equipped with scatters equipment, make sawdust fully
touched with the hot air,so that have a very good drying effect.
The simeple of sawdust rotary dryer system
Usage Of sawdust rotary dryer
Sawdust rotary dryer is used for drying materials with a certain humidity lightweight material, such as bean dregs, sawdust,wood chips,cassava dregs,Marc,distiller'sgrains,and others.
Our special design sawdust rotary dryer has a strong adaptability of materialsand it can dry
various materials. This type sawdust rotary dryer operation is very simple and liable. Also our professional sawdust rotary dryer has playing important role in various drying industries,sawdust rotary dryer
is used for drying materials with humidity or granularity in the industries of mineral dressing, building material, metallurgy and chemical.Sawdust rotary dryer can be used fordrying many kinds of
materials and with convenient and reliable operation; therefore, it has been widely used.
Sawdust rotary dryer working site:
Features of sawdust rotary dryer :
1. Our sawdust rotary dryer is designed with anti-sticky drum-wall and assembled material-lifting board.
2.This type sawdust rotary dryer,what worth mentioning is that our rotary drum dryer
features convenient installation and transportation as a result of its flange
connection.
3. This large sized sawdust rotary dryer is primarily composed of feeder conveyor,
heating furnace, drying device, and air intake and air outlet device, and more.
4. Our sawdust rotary dryer has the features of low noise, little pollution and good
drying effect.
The technology Parameters of Sawdust Rotary Dryer:
Model |
Diameter (m) |
Length (m) |
speed |
Installation obliquity (%) |
Drying temperature (°c) |
Capacity (t/h) |
Motor (kw) |
Weight (ton)
|
Φ0.8x8 |
0.8
|
8 |
3-6 |
3-5% |
≥800 |
0.6-0.8 |
3 |
3 |
Φ1.0x10 |
1.0
|
10 |
3-6 |
3-5% |
≥800 |
1-1.5 |
4 |
7 |
Φ1.2x10 |
1.2
|
10 |
3-6 |
3-5% |
≥800 |
1.8-2 |
7.5 |
14 |
Φ1.2x12 |
1.2
|
12 |
3-6 |
3-5% |
≥800 |
2-3 |
11 |
15 |
Φ1.5x15 |
1.5
|
15 |
3-6 |
3-5% |
≥800 |
3-3.5 |
15 |
20 |
Φ1.8x18 |
1.8
|
18 |
3-6 |
3-5% |
≥800 |
5.0-5.5 |
18.5 |
30 |
Φ1.8x20 |
1.8
|
20 |
3-6 |
3-5% |
≥800 |
5.5 |
18.5 |
33 |
Φ2.2x20 |
2.2
|
20 |
3-6 |
3-5% |
≥800 |
6.5-7.0 |
22 |
56 |
Φ2.4x20 |
2.4
|
20 |
3-6 |
3-5% |
≥800 |
7.5-8 |
30 |
60 |
Φ2.5x20 |
2.5
|
20 |
3-5 |
3-5% |
≥800 |
8-9 |
30 |
63 |
Φ2.5x25 |
2.5
|
25 |
3-5 |
3-5% |
≥800 |
10-11 |
37 |
68 |
Φ2.8x20 |
2.8
|
20 |
3-5 |
3-5% |
≥800 |
13-15 |
45 |
75 |
Φ2.8x30 |
2.8
|
30 |
3-5 |
3-5% |
≥800 |
18-20 |
55 |
83 |
Φ3.0x20 |
3.0
|
20 |
3-5 |
3-5% |
≥800 |
18-20 |
55 |
78 |
Φ3.0x22 |
3.0
|
22 |
3-5 |
3-5% |
≥800 |
20-25 |
55 |
80 |
Φ3.0x30 |
3.0
|
30 |
3-5 |
3-5% |
≥800 |
25-28 |
75 |
90 |
Export standard container 20GP OR 40GP,40HQ,FR container,In bulk,the spare parts in wooden case.
Some case of our rotary dryer shipping to customer
Henan Donging Heavy Industry Equipment CO.,LTD is a new energy equipment, high humidity material drying equipment, environmental protection and research-based professional development of enterprise groups, is the only domestic industry drying equipment research and development, design, production and sales of high-tech enterprise group, and the first certified by ISO quality management system. Dongding Heavy Industry Equipment is a project co-drying equipment, Tsinghua University, Henan University research base, China Petroleum and Chemical Industry Federation drying technology professional group member units, Henan Province, the top ten most of the growth of science and technology enterprises.
As a professional manufacture,we are supply machinery as below:
1.) Rotary dryer,Sawdsut rotary dryer, Lignite dryer,Brewer grain dryer and other dryer
2.) Wood pellet machine, Biomass pellet machine, Animal feed pellet machine,Small pellet machine
3.)Coal gasifier,Biomass gasifier,MSW gasifier,Sawdust burner,wood pellet burner,biomass pellet burner, wood/biomass prowder burner and others
4.)wood chipper,wood hammer mill,wood crusher and other machine.
