[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

Shandong Rotex Machinery Co., Ltd. Gold Verified Supplier
5Yrs
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust thumbnail-1
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust thumbnail-2
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust thumbnail-3
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust thumbnail-4
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust thumbnail-5
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust thumbnail-6
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust photo-1
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust photo-2
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust photo-3
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust photo-4
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust photo-5
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust photo-6
US$ 9,700 - 12,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
ROTEXMASTER
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port hammer mill
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name ROTEXMASTER
Model Number YSG65*100
Voltage 22O-440V
Power(W) 90-110KW
Dimension(L*W*H) 2400*1000*1100MM
Weight 2300KG
Certification CE ISO
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

Cynthia Tel:8613165110202 Skype:woodpelletmachine19



Brief Introduction

The multifunctional hammer mill's working principle is that when the material enters into the crusher,grinded by the beat, fraction power from the high speed rotating hammers, then the required power screened by the sieve.

The YSG series hammer mill can crush the wood chips, rice husk, agricultural stalk/straw pieces, and shell or grain crops. Meanwhile, the hammer mills grind the PVC and rubber with water cooling system, so it called the multifunctional hammer grinding machine.

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

Technical Paremeters of YSG65*100 Hammer Mill

Model

YSG65*100

Power(kw)

90-110

Capacity(t/h)

3-4

Hammers

96

Weight  (t)

2.3

Dimensions(mm)

2400*1000*1100

Advantages

1.The motor and rotor are installed in the same heavy-duty base, using coupling direct drive, rotor passes accurate dynamic balancing test, the hammers are arranged symmetrically.

2.Unique Feeding Design, the feeding inlet is made at the side of the device to make feeding easily.

3.The shell is welded by steel plate, the site in the crush room which connects to the materials all use the wearable and commutative parts and double wear plate.

4.Hammers adopts special abrasion resistent treatment technology, extend its lifetime greatly.

Product Show

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust
[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

Technical Parameters

Model

Power(kw)

Capacity t/h

Hammers

Weight  (t)

YSG40

7.5

0.2-0.5

16

0.27

YSG50

15

0.6-0.8

16

0.45

YSG65*27

22

0.8-1.5

24

1.1

YSG65*55

37

1-2

48

1.5

YSG65*75

55

2-3

72

1.9

YSG65*100

90

3-4

96

2.3

YSG130*55

110

5-6

80

5.3

YSG130*100

160

7-8

160

6.8

More details show

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

Wood hammer mill machine in wood pellet production line

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

After-sale Service

1.Company adhere to the " Service & Quality First, Brand & Reputation First " Principle to provide our customers the best quality service. Welcome thecustomers to visit our factory.

2.Our professional service includes: free training, guidance, installation, and debugging.

3.After selling, we provide the warranty of one year.

4.If you have any problems, we will help to solve on line or live in time.

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

Company Show

ROTEX is an enterprise combined of science and technology, which is specialized an manufacturing and installation training and international trade. Especially in the energy shorttage today, starting from customers' interests, standing in the perspective of customers, to provide our customer the best service, we should like to use our professional knowledge and design the most suitable chart flow and produce the best much better products.

We are doing biomass fuel machinery, fodder farming machinery, and supporting the auxiliary equipment of  dryer, cooler, dust removal equipment and other machinery products, the main products: wood pellet machine,feed pellet machine, drum wood chipper and hammer mill, rotary dryer, cooling equipment, conveyors equipment and other auxiliary equipments.

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust

[ROTEX MASTER] Wood Hammer Mill Machine For Producing Sawdust





Dear manager.

Thanks for your reading.

If you are interested in our machines, please kindly tell me.

You can give me an email, or we can chat online by whats app,  skype.

Or you can leave me a message in the below chart.

Please kindly tell me the machine you want , the raw material condition, the  capacity requirement, the voltage condition etc.

I am Cynthia, glad to hear from you.
