Production line/Making Machinery for peanut butter

according to your requiremet

Specifications

1.stainless steel material
2.differen capacity
3.no pollution
4.have stock.

1.Description of peanut butter machine

The unit equipment has high mechanization level,high reliability,and it is fully sealed.So it can process high-quality level of peanut butter and ordinary peanut butter.Moreover,it can also produce steady type and ordinary sesame butter.



2. peanut butter production line

materials-----eliminating the impurity-----roasting-----cooling-----peeling-----selecting-----coarse grinding-----mixxing into food assitives-----accurate grinding-----removing the air-----cooling-----filling



3.peanut butter machine Main Equipment

 Elevator/Hoisting Machine, Foreign Matter Removal Machine,Peanut Roaster, Conveying Belt, Cooling Belt, Peeling Machine, Selecting/Picking Belt, Automatic Feeding Device, Rough Grinding Machine, Mixing and Conveying Device, Refining Mill, Cooling and Mixing Machine, Vacuum De-air Machine, Filling Machine.



4.Detailed Product Description



Elevator--Roasting---Cooling--Peeling--Selecting --Milling--Mixing--Cooling--de-gasing--Liquid filling machine



peanut butter machine--Roasting:

Batch roaster’s working temperature is 200-210 ºC, 20-30minutes.use batch roaster will bake some delicious smells.



peanut buttr machine--Cooling:

Peanut will be send cooling belt to cool.



peanut butter machine--Peeling:

put the roasted peanuts into peeler to take off the red skin,

 the double rollers will frication the red skin, the simple cyclone system will suck

the red skins, most of them will be put in half-piece, then fall to the selecting conveyor, the over-roasted and

un-blanched peanut kernel is picked up by manual or mechanical.

 (It is matched with manual type conveyor in the quotation)



peanut butter machine--Primary grinding:

Using steel grinder to make the first grinding;





peanut butter machine--Second grinding:



Using colloid grinder to make the second grinding, the fineness of grinding is



controlled below 7um, temperature of grinding is controlled below 68C.



peanut butter machine--Mixing: make the butter more homogeneous



peanut butter machine--Cooling:

the butter through second grinding should be cooled immediately.

The temperature should go down 45C.



peanut butter machine--Degasser : Take out the air from peanut butter.



peanut butter machine--Storage tank:

 settling down in the storage tank till the temperature drop to air

temperature.



peanut butter machine---Packing:

by the filling machine, the finished peanut butter is packed into 200g/500g/1000g bottle
