CE/GOST/SGS 0.5-5.5t/h ring die sunflower stalk pellet mill

Specifications

1.One year warranty
2.ISO 9001:2000; CE, GOST, SGS
3.Gear drive
4.Ring die pellet

  We are specialized in designing and manufacturing poultry feed,aquatic feed pellet machinery,biomass pellet machinery and the complete production line(all auxiliary equipment) with CPM advanced technology.



The current products include: hammer mill, ingredient weighing system, mixer, pellet mill, counter-flow cooler, dryer, crumbler, rotary screener, liquid adding equipment, pulse filter equipment, horizontal and vertical conveying equipment, links and gates, permanent magnet cylinder, and de-iron equipment etc.



Features



1. It is widely used to make pellets from light substance, such as wood chips, sawdust, straw, pasture, chrysanthemum, palm leaf and so on;



2. The feeder’s especial structure makes materials conveyed evenly, it is specially designed for pellet of light substance with the density of 0.3-0.6g/ cm³;



3. Feeder, conditioner and chute are made of stainless steel with long service life;



4. It is with magnet and over load protection system, which protects the machine during production;



5. Feeder has a variable speed controller to meet different outputs requirements;



6. It makes gear directly-connecting as the driver, and is with quick-release die fixed by clamps, which will increase the output by 15% when compared to a machine with a belt conveyer;



7. The bearing and oil seal in the main drive are imported from Japan to ensure highly-efficient, stability and high quality;



8. The alloy steel die is with international advanced equipment and techniques, and has long service life, and can make  slippery pellets of the highest quality.





Main Technical Parameters



Model	Main Power(KW)	Capacity(t/h)	Pellet Size(mm)
RD350MX	55	0.5~0.7	6, 8, 10
RD400MX	75/90	0.7~1.0	6, 8, 10
RD420MX	90/100	0.8~1.5	6, 8, 10
RD508MX	132/160	2.0~2.5	6, 8, 10
RD678MX	220/250	2.5~3.5	6, 8, 10





Liyang Rongda Feed Equipment CO.,LTD. located in Daitou Industrial Zone with 25000 square meters area,Liyang city,Jiangsu province,China.





Goods are made by our factory.







Our certificates:ISO9001:2000,CE,GOST,SGS



Delivery Management: When the container arrived our factory, our shipping operator and delivering equipments will be ready on time to ensure goods shipped based on Sales Order requirement.
