RD 400/420 Livestock Feed Pellet Mill

Specifications

1. CE and GOST Certificated
2. Easy Installation
3. High Efficiency
4. Competitive Price

 We are specialized in designing and manufacturing poultry feed,aquatic feed pellet machinery,biomass pellet machinery and the complete production line(all auxiliary equipment) with CPM advanced technology.



The current products include: hammer mill, ingredient weighing system, mixer, pellet mill, counter-flow cooler, dryer, crumbler, rotary screener, liquid adding equipment, pulse filter equipment, horizontal and vertical conveying equipment, links and gates, permanent magnet cylinder, and de-iron equipment etc.





SZLH400/420 High Rank Livestock Feed Pellet Mill



Features



1. Gear directly-connecting driving is adopted for high efficiency;

2. Full stainless steel feeder; variable pitch anti-bridging structure; Imported FC control;

3. LL stainless steel conditioner with axial steam spraying extends the conditioning and cooking time;

4. Main gear and pinion shaft adopt the carbonizing quenching with high accuracy; smooth driving,low noise and long service life.

5. Gearbox and driving holes accuracy are guaranteed by specialized casting supplier and NCC.

6. The bearing and oil seal in the main drive are imported, and especially lubrication oil return system is available to ensure reliable bearing lubrication;

7. 2 pc quick disassembling type precisely-cast die clamp is adopted to connect the die and quill flange, resulting in convenient and quick disassembling of die.

8. Pellet chamber door and feed chute are fully made of stainless steel with high anti-corrosion ability and long service life.

9. The connection between motor and gearbox adopts new type S-shape spring coupling with more convenient disassembling and assembling and more reliable use.



Main Technical Parameters



Model	Outputt/h	Main PowerKw	Power of Conditioner (Kw)	Power of Feeder (Kw)	ID Of Die (mm)	Pellet Size (mm)
SZLH400	3-12	75/90	5.5	1.5	400	2-18
SZLH420	3-14	90/110	5.5/7.5	1.5	420	2-18





Liyang Rongda Feed Equipment CO.,LTD. located in Daitou Industrial Zone with 25000 square meters area,Liyang city,Jiangsu province,China.







Goods are made by Rongda company.
