2013 hot price! Horizontal Ribbon Mixer for powder dry

Specifications

Ribbon mixer
1.High-efficient machine
2.CE,GOST,SGS approved
3.Supply assessment
4.One year warranty



SLHY Horizontal Ribbon Mixer for powder dry

   We are specialized in designing and manufacturing poultry feed,aquatic feed pellet machinery,biomass pellet machinery and the complete production line(all auxiliary equipment) with CPM advanced technology.



   The current products include: hammer mill, ingredient weighing system, mixer, pellet mill, counter-flow cooler, dryer, crumbler, rotary screener, liquid adding equipment, pulse filter equipment, horizontal and vertical conveying equipment, links and gates, permanent magnet cylinder, and de-iron equipment etc.



SLHY single shaft mixer



Usage:

It is widely used for mixing of power materials in the industries of feed, grainm food, flour, chemicals, etc.



Features:

1.There is no mixing dead corner and the mixing variation coefficient CV≤7%.



2.The gap between rotor and housing can be adjusted. The materials are dscharged at full bottom with less remainder.



3.The end shaft adopts filler for sealing, thus avoiding the leakage at both ends of shaft;



4.The discharging gate adopts pneumatic ( or electric) gate opening, resulting in correct and reliable motion and good tightness;



5.There are built-in liqid adding pipe and atomizing nozzles;



6.It has reasonable structure, fine apearance and convenien operation and maintenance.



Item   Model	Volume m3	Mixing Amount per Batch(kg)	Mixing Time Per Batch(m)	Mixing Homogeneity (cv≤%)	Power(kw)
SLHY 0.6	0.6	250	5-7	7	5.5
SLHY 1	1	500	5-7	7	11
SLHY 2.5	2.5	1000	5-7	7	15
SLHY5	5	2000	5-7	7	30
SLHY 7.5	7.5	3000	5-7	7	45
SLHY 10	10	4000	5-7	7	55
SLHY12.5	12.5	5000	5-7	7	75































 Double shaft mixer





SLHY single shaft mixer



Feed equipment line

Production Sequence

 1. Receiving and pre-cleaning Process

 2. Grinding Process

 3. Proportioning and mixing process

 4. Pelleting Process

 5. Sifting and cooling Process

 6. Bagging Process















Delivery process







Company introduce



    Liyang City Rongda feed Equipment Co., Ltd., was established in January 2005, is located in the superiorinvestment environment in Tai Tau Industrial Area,covering over 25,000 m2, building area of more than 13,000 square meters, office building covers an area of?more than 500 square meters.
   The Rongda company is the one for many yearsspecialized in biomass.....





Certificate









Why buy from us?
1.Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2.Delivery fast -----Goods be sent out within 15 to30 days based on order quantity.
3.Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4.Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
