CE/GOST/SGS Certificate Counterflow Cooler Cooler

Liyang Rongda Machinery Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name RD

Specifications

The counter-flow cooling principle is adopted to cool the pellets with high temperature and moisture.

PRODUCT FEATURES

The counter-flow cooling principle is adopted to cool the pellets with high temperature and moisture.Hot air touches hot pellets and cool air touches cool pellets so as to avoid pellet surface crack caused by sudden cooling produced by direct touching between cool air and hot pellets;
Cooling volume is enlarged,cooling time of pellets is extended and cooling effect is greatly improved;
Air-enclosed feeder is adopted for feeding so as to avoid the air crossing at the feeding inlet,resulting in good cooling effect;
There is an adjustable built-in taper spreader,resulting in even distribution of pellets;
The top of cooler is made of stainless steel,resulting in high corrosion-resistance and long service life.
Slide reciprocating discharger has smooth and reliable discharging;

Technical Parameters

Model Parameters	SKLN1.5 15×15	SKLN2.5 18×18		SKLN 4 20×20	SKLN6 24×24		SKLN8 26×26
Cooling Volume (m³)	1.5	3		4	6		8
Capacity (t/h)	3	5		10	15		20
Cooling Time (min)	less than 10-15
Product Temp. after cooling	Not 3~5°C higher than ambient temperature
Air Absorbing Volume (m³/min.t)	34
Power (KW)	0.75	1.1	1.5		1.5	2.2
Power of Airlock (KW)	0.55	0.75 00.75.55	0.75		1.1	1.1
