Specifications
pellet screw conveyor1.transmission length3-70m
2.high capacity 7.3-84.4t
3.ISOcertificate
4.cement,coal,sand,cereal,etc
good quality pellet screw conveyor from china
I. Introduction of pellet screw conveyor:
GX screw conveyor is specialized in designing, manufacturing and supplying of horizontal, inclined and vertical conveyor systems to meet the rigorous demands required in a wide range of powdery, granular and small block material in building material, chemical engineering, power, metallurgy, coal, grain industry, etc.
II. Application of pellet screw conveyor:
Sand and Cement, Food Waste, Wood Chips, Aggregates, Cereal Grains, Animal Feed, Boiler Ash, Meat and Bone meal, Municipal Solid Waste, and many others
III. Features of pellet screw conveyor:
1. Large load ability, long service life
2. Efficient and flexible in design and arrangement.
3. Rapid and even transfer of non abrasive materials from horizontal to various angles
4. End discharge gate ensures easy and thorough cleaning
5. Easy installation. Field assembly requires only following match-marks and installation instruction
6. Convenient in maintenance
7. Carbon steel and SS304 are standard. Can be galvanized for corrosive conditions.
VI. Main technical parameters of pellet screw conveyor:
Model |
Transmission length |
Capacity (T) |
Motor power(KW) |
Weight(T) |
||
Coal |
Cement
|
Raw material |
||||
GX200X10M |
3-70M |
8.5 |
7.9 |
7.3 |
2.2 |
0.7 |
GX250X10M |
3-70M |
16.5 |
15.6 |
13.8 |
3 |
0.95 |
GX300X10M |
3-70M |
20 |
21 |
18.7 |
3 |
1.4 |
GX400X10M |
3-70M |
54 |
51 |
45 |
5.5 |
2.1 |
GX500X10M |
3-70M |
79 |
84.4 |
74 |
7.5 |
3.2 |
