Specifications
grain screw conveyor1.ISO certificate
2.high capacity 8.5-79t/h
3.motor power2.2-7.5kw
4.used for coal,cement,etc.
widely application GX series grain screw conveyor
I. Operating principle of screw conveyor:
GX type screw conveyor is a continuous conveying equipment. It is used for transporting all kinds of powder and small pieces of material, such as Coal, cement, sand, coal, grain, etc. It will use revolving the screw the material which will transport along the fixed cabinet to pass carries on the transportation work.
II. Features of screw conveyor:
Structure is simple, operation safety is convenient, the upkeep is not very complicated, the cross section external form the dimension is not big , easy to carry out load-off on some location, confinement machine shell cover may reach fairly good hermetic sealing.
III. Application fields of screw conveyor:
The machine may be used for branches such as chemical industry, building material, machinery, coal, metallurgy, light industry, grain, medicine, traffic, water and electricity broadly, Being used to transport all kinds of form of powder and small piece material. Be inadvisable to transport the big viscidity packing material or large piece of material easy to go bad. This enables the installation slightly tilted, the maximum tilt angle: less than or equal 20°, the working environment temperature: -20°C ~ 50°C temperature materials transportation: less than 200°C.
IV. Main technical data of screw conveyor:
Model |
Transmission length |
Capacity (T) |
Motor power(KW) |
Weight(T) |
||
Coal |
Cement
|
Raw material |
||||
GX200X10M |
3-70M |
8.5 |
7.9 |
7.3 |
2.2 |
0.7 |
GX250X10M |
3-70M |
16.5 |
15.6 |
13.8 |
3 |
0.95 |
GX300X10M |
3-70M |
20 |
21 |
18.7 |
3 |
1.4 |
GX400X10M |
3-70M |
54 |
51 |
45 |
5.5 |
2.1 |
GX500X10M |
3-70M |
79 |
84.4 |
74 |
7.5 |
3.2 |
