China Dry Process Rotary Kiln Best Selling

China Dry Process Rotary Kiln Best Selling thumbnail-1
China Dry Process Rotary Kiln Best Selling photo-1
US$ 60,400 - 1,311,476 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Induction Furnace
Usage:
Heat Treatment Furnace
Contact Supplier Request Quote Chat Now
Henan Yuhui Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Dalian Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Induction Furnace
Usage Heat Treatment Furnace
Place of Origin Henan, China
Brand Name Yuhui
Model Number many types
Voltage 380V or as ordered
Power(W) different model
Dimension(L*W*H) different model
Weight different model
Certification ISO, BV
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

china dry process rotary kiln best selling
1.Durability
2.Low cost and low noise
3.ISO9001:2000&CE

                                         china dry process rotary kiln best selling

 china dry process rotary kiln best selling

1.Introduction of rotary kiln

  • 1. The basic components of a rotary kiln are the shell, the refractory lining, support tyres and rollers, drive gear and internal heat exchangers.
  • 2. rotary kiln is our most best selling product in foreign countries, we export to Vietnam, Indonesia, India, America, Canada, Malasia and so on, one of most pupolar procuct.

2 other equipment connection with rotary kiln



  • The kiln connects with a material exit hood at the lower end and to ducts for waste gases.
  • The exhaust gas may go to waste, or may enter a preheater which further exchanges heat with the entering feed. The gases must be drawn through the kiln, and the preheater if fitted, by a fan situated at the exhaust end
  •  In preheater installations which may have a high pressure-drop, a lot of fan power may be needed, and the fan is often then largest drive in the kiln system. Exhaust gases contain dust and there may be undesirable constituents such as sulfur dioxide or hydrogen chloride. Equipment is installed to scrub these out before the exhaust gases pass to atmosphere.

3. main technical data of rotary kiln



Specification
(mm)

Kiln demensions

Output(t/h)

Rotation speed(r/min)

Moto power(kw)

Weight

Note

Diameter
(mm)

Length
(mm)

Obliquity
(%)

(t)

ø1.4*33

1.4

33

3

0.9-1.3

0.39-3.96

18.5

47.5

----

ø1.6*36

1.6

36

4

1.2-1.9

0.26-2.63

22

52

----

ø1.8*45

1.8

45

4

1.9-2.4

0.16-1.62

30

78.2

----

ø1.9*39

1.9

39

4

1.65-3

0.29-2.93

30

77.59

----

ø2.0*40

2

40

3

2.5-4

0.23-2.26

37

119.1

----

ø2.2*45

2.2

45

3.5

3.4-5.4

0.21-2.44

45

128.3

----

ø2.4*40

2.4

40

3.5

6.2-6.8

0.39-2.44

55

136.5

----

ø2.5*40

2.5

40

3.5

9.0-10.5

0.44-2.44

55

149.61

----

ø2.5*50

2.5

50

3

6.25-7.4

0.62-1.86

55

187.37

----



 china dry process rotary kiln best selling

 Rotary kiln big gear
