Specifications
Vertical wet Grinding Machine1.Envirommental friendly
2.Sophisticated equipment
3.Yuhui, let quality speak
Vertical wet Grinding Machine
1. Self-floating gold grinding machine / wet grinding machine
fundamentaly solve the problem of mixing equipment, mixing evenly, the air discharged from a number of difficult problems is refractory raw material before molding The most novel dealing with the most appropriate professional equipment, this machine is mainly through the mixing of raw materials - Rolling - broken - after repeated rolling up moisture balance, the ratio is even, the gas content is low, increase the rate shaping and forming quality, through the grind of the material forming machine products, with high density, high strength, non-porosity ratio of weight and so on.
2. 350 wet-grinding machine is suitable for use by SMEs. 750 gold grinding machine / wet grinding machine suitable for large and medium enterprises to use, factory production of gold grinding machine / wet grinding machine can be prepared by sealing cover to prevent air pollution.
3. As a hybrid device called the wet-grinding machine, its structure and dry mill similar to, but Nianpan were no sieve, grind ram lighter, there are discharging institutions. Will be coordinated with milled in feed and water joined by mixing evenly, the agency will use discharge material unloading. Stir in the mixed process of both have compression can be better to exclude the air between the material particles, so that the mixture of soil moisture uniform material, particle surface wetting sufficient mixing effect is good, but the size of the materials are some damaging effects. Wet grinding machine more cumbersome, yield lower energy consumption more, but mixing soil material and good quality.
.
Cone Wet Grinding Machine main technical parameters:
Model | Specification(mm) | Feeding size | Speed(r/min) | Power(kw) | Weight(t) |
1600A | 1600*500*200*500+20 | Feeding size less than 3cm | 20-22 | 37 | 14.5 |
1500A | 1500*350*200*460+20 | 20-22 | 22 | 13.3 | |
1500B | 1500*350*150*460+20 | 20-22 | 22 | 12.3 | |
1500C | 1500*300*150*420+20 | 20-22 | 18.5 | 11.3 | |
1400A | 1400*250*150*350+20 | 16-18 | 18.5 | 8.5 | |
1400B | 1400*250*150*350+20 | 21-23 | 18.5 | 8.5 | |
1350A | 1350*250*150*350+20 | 16-18 | 18.5 | 8 | |
1350B | 1350*250*150*350+20 | 21-23 | 18.5 | 8 | |
1300A | 1300*250*150*350+20 | 16-18 | 15 | 7.5 | |
1300B | 1300*250*150*350+20 | 21-23 | 15 | 7.5 | |
1200A | 1200*220*80*270+20 | 17-19 | 7.5 | 5.5 | |
1200B | 1200*200*80*250+20 | 23-25 | 7.5 | 5.5 | |
1100A | 1100*200*80*250+20 | 17-19 | 7.5 | 5 | |
1100B | 1100*200*80*250+20 | 23-25 | 7.5 | 5 | |
1000 | 1000*200*80*250+20 | 13-15 | 5.5 | 4.5 |
....
