Specifications
Snack Food Making Equipment Machine* Max capacity 500kg/h
*Twin screw extruder
*S.S201/304/316
*CE certificate
Snack Food Making Equipment Machine
1.Production Description
- Snack food making equipment machine can take corn, rice, wheat, oat, rye and other grains as materials to produce extruded snacks, with crispy taste and lively shape, Inflating food machine is designed according to market demand.We can get different shapes: round, triangle, square, stars, flower, etc.
- This processing line from feeding, extruding, shaping ,cutting,oil spraying to finished products are done once time automatically. Visible auto-temperature controlling system, make the temperature-controlling to be more direct-viewing, parameter to be more precise.
- The screws are made by ally steel and special craft, the screw life is longer, uses building block system structure, may combine willfully. The forced lubrication system, by guaranteed equipment transmission longer life.
2. Flow chart:
- Mixing—Extruding—Conveying---Baking—Spraying--Seasoning
3. Equipments
- Mixer--Screw Conveyor—Twin-screw Extruder—Air conveyor—Three-layer Oven—Elevator—Oil Sprayer--Roller
Parameter | Mixer | Extruder
| Air Conveyor | Five-layer roasting oven | Hoister | Oil spray | Flavor | Rollers |
Model | BFJ—II
| LRS65 | FSJ—II | HGD-5-III | TSJ | GPY--II | TW | SGT--IV |
Installed Capacity(kw) | 4 | 57.75 | 1.1 | 45 | 0.75 | 4.37 | 0.37 | 1.5 |
Power Consumption (kw) | 3 | 30 | 1.1 | 30 | 0.5 | 3 | 0.37 | 1.5 |
Output(kg/h) | 300 | 250 | 200 | 280 | 150 | 150 | 150 | 300 |
4. Picture of processing line:
5. Mould:
6. Sample:
7.Our service:
a.) Consultation service before, during, and after sales;
b.) Project planning and design services;
c.) Debugging of equipment until everything is functional;
d.) Management of equipments' long distance shipping from seller's factory to named place by buyer;
e.) Training of equipment maintenance and operating personally;
d.) New production techniques and formulas;
f.) Provide 1 year complete warranty and life-time maintenance service;
