Specifications
Delicious Snack Food Machine LRS70-II* Processing snack food
*Twin screw extruder
*Full automatic
*Max output 280kg/h
Delicious Snack Food Machine LRS70-II
1. Description:
Snacks extruder adopts corn starch, rice starch, wheat, oat, barley etc as raw materials to make puff snacks. Through friction of screw and barrel, the grains are cooked in the extruder. Forming is at the die face cutter. The product shape is determined by a combination of the die aperture, including ball, tube, stick, ring, fruit loop, star, wheel and flower etc.
2. Raw materials: adopts corn, rice, wheat, oat, barley etc as ingredients
3. Products: Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower and heart shape by adjusting the mould in the extruder
4. Capacity: 100-150kg/h, 200-260kg/h, 400-500kg/h for option
5. Flow chart: Mixing system---Extrusion system---- -Drying system----Flavoring system---Packing system
6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers Local voltage according to different countries
7. Machines Materials: All the machines are made by stainless steel
8. Technical Parameters
|
Parameter |
Mixer |
Extruder
|
Air Conveyor |
Five-layer roasting oven |
Hoister |
Flavor |
Oil spray |
Rollers |
Model |
BFJ—II
|
LRS70-II |
FSJ—II |
HGD-5-III |
TSJ |
TW |
GPY--II |
SGT--IV |
Installed Capacity(kw) |
4 |
57.75 |
1.1 |
45 |
0.75 |
0.37 |
4.55 |
1.5 |
Power Consumption (kw) |
3 |
30 |
1.1 |
30 |
0.5 |
0.37 |
3 |
1.5 |
Output(kg/h) |
300 |
300 |
150 |
150 |
150 |
150 |
200 |
200 |
Dimension(m) |
1×0.7×1.4 |
2.6×0.9×1.9 |
1.5×0.6×0.9 |
5.0×1.3×2.3 |
1.3×0.5×0.6 |
2.3X0.8X1.3 |
1.0×0.6×0.8 |
3.2×0.8× 2.3 |
9. Package:
