Specifications
3D single-screw extruder food process linepetitive price
2.excellent quality
3.high output
4.accurate parameter
3D single-screw extruder food process line
Description:
Single-screw chips processing line adopts the flour, corn starch, and potato starch as the raw material then forms a kind of leisure food after extruding, slaking, forming, dying, frying and inflating. According to different molds, this processing line can product different shapes of productions like shell, spiral, square tube, round tube, lotus, thorn snail, pig’s large intestines.
Raw Material: the flour, corn starch, and potato starch
Capacity: LRD---100 100KG/H—120KG/H
Consumption: 65.3kw, if you are concerned about the high consumption of the Electric Dryer, it could be changed into Gas Type.
Machine Surface: Stainless Steel
Flow Chart: Mixer-----Extruder-----Cooler-----Dryer-----Fryer-----Roller
Technical parameter of machine
NO | Machine | Motor Power | Capacity | Dimension | Quantity | Function |
1 | Mixer | 4KW | 50kgs /once time | 0.8*0.7*1.5m | 1set | To mix the raw materals with the water |
2 | Screw conveyer
| 1.1KW | 100-150kg/h | 3.0*0.8*2m | 1set | To send the materials to the extruder |
3 | CYS-100 Single screw extruder | 30KW | 80-100kg/h | 4.0*1.2*3.0 m | 1set | To extrude the food.the main machine of the line |
4 | Cutting machine | 1.1KW | 80-150kg/h | 2.4*0.6*1.3 | 1set | To cut the macaroni to the 3D shape |
5 | Shifte | 0.55KW |
| 2.0m length | 2sets | To cool and sifting the 3Dpellet snacks |
6 | 5layers 5meter oven |
| 80-120kg/h | 5.0*1.4*2.5m | 1set | To dry the 3D pellet snacks |
7 | Fryer | 65KW | 100-200kg/h | 4.0*1.3*2.0m | 1set | To frying the 3D snacks to the final product |
8 | Single flavoring roller | 0.55kw | 150kg/h | 2.1*1.1*1.9m | 1set | To flavor the 3D pellet snacks |
After-sale Service:
a. 12 months free warranty
b. offer onsite installation and debugging and personal training
c. regular visits
d. all machines we offered are lifetime maintenance
e. accessories are guaranteed to change in 12 months and sold at cost price after 12 months.
Sample Photos:
| | |
| | |
| | |
Mixer--- Single-screw extruder-----Conveyer& Cutter-----Elevator------ dryer----- fryer-----flavor----roller
