Beverage storage tank made by food grade stainless steel

Specifications

1.Material: SS304 or SS316
2.Storage liquid,food etc.
3.Single-layer;3-layer
4.Easy to operate
5.Type:vertical /horizon

[Product name] Beverage storage tank made by food grade stainless steel



[Product introduce]





Applicable range



1. Used as liquid storage tank, liquid composing tank, temporary storage tank and water storage tank etc.

2. Ideal in field such as foods, dairy products, fruit juice beverages, pharmacy, chemical industry and biological engineering etc.



Configuration of tank



1. Quick open manhole.

2. Various types of CIP cleaners.

3. Fly and insect resistant sanitary breathing cover.

4. Adjustable triangular bracket.

5. Dismountable materials input pipe assembly.

6. Thermometer (According to customer requirements).

7. Ladder (According to customer requirements).

8. Liquid level meter and level controller (According to customer requirements ).

9. Eddy-proof board.



Technical parematers





Effective volume	Dimension                 of tank	Total height	Diameter of      inlet&outlet	Heat preservation layer	Motor power	Blending speed
(L)	(mm)	(mm)	(mm)	(mm)	(kw)	(r/min)
500	840*1000	2750	60	38	0.55	Common rotation speed 35,43,60 ; stepless speed reducer or dual-speed reducer are also available
600	920*1000	2850	60	38	0.55
700	990*1000	2850	60	38	0.55
800	950*1220	3000	60	38	0.55
900	1010*1220	3000	60	38	0.55
1000	1060*1220	3150	60	51	0.75
1500	1160*1500	3350	60	51	0.75
2000	1340*1500	3410	60	51	1.1
3000	1410*2000	4000	60	51	1.5
4000	1620*2000	4250	60	51	1.5
5000	1810*2000	4300	60	51	2.2
6000	1980*2000	4550	60	51	2.2
7000	1930*2440	5000	60	51	2.2
8000	2060*2440	5000	60	51	3
9000	2180*2440	5050	60	51	3
10000	2300*2440	5050	60	51	3
12000	2270*3000	5600	60	51	4
15000	2530*3000	5700	60	51	4
20000	2640*3660	6400	60	51	5.5
