Specifications
1.Material: SS304 or SS3162.Storage liquid,food etc.
3.Single-layer;3-layer
4.Easy to operate
5.Type:vertical /horizon
[Product name] Stainless steel tank / Mixing tank / storage tank
[Product introduce]
Description
According to different storage ability within 50L15000L ,storage pot whose storage ability is up to
20000L is suggested to use outdoor storage. Storage pot is made of SUS304 or SUS316 stainless
steel and has good heat preservation performance .
Its attached devices are as folows; inlet and outletenter holethermometer liquid level indicator, fly-proof ,dustproof breathing ail hole,asepsis sampling gage,Meter. CIP cleaning nozzle.
Configuration of tank
1. Quick open manhole.
2. Various types of CIP cleaners.
3. Fly and insect resistant sanitary breathing cover.
4. Adjustable triangular bracket.
5. Dismountable materials input pipe assembly.
6. Thermometer (According to customer requirements).
7. Ladder (According to customer requirements).
8. Liquid level meter and level controller (According to customer requirements ).
9. Eddy-proof board.
Technical parematers
| Effective volume | Dimension of tank | Total height | Diameter of inlet&outlet | Heat preservation layer | Motor power | Blending speed |
| (L) | (mm) | (mm) | (mm) | (mm) | (kw) | (r/min) |
| 500 | 840*1000 | 2750 | 60 | 38 | 0.55 | Common rotation speed 35,43,60 ; stepless speed reducer or dual-speed reducer are also available |
| 600 | 920*1000 | 2850 | 60 | 38 | 0.55 | |
| 700 | 990*1000 | 2850 | 60 | 38 | 0.55 | |
| 800 | 950*1220 | 3000 | 60 | 38 | 0.55 | |
| 900 | 1010*1220 | 3000 | 60 | 38 | 0.55 | |
| 1000 | 1060*1220 | 3150 | 60 | 51 | 0.75 | |
| 1500 | 1160*1500 | 3350 | 60 | 51 | 0.75 | |
| 2000 | 1340*1500 | 3410 | 60 | 51 | 1.1 | |
| 3000 | 1410*2000 | 4000 | 60 | 51 | 1.5 | |
| 4000 | 1620*2000 | 4250 | 60 | 51 | 1.5 | |
| 5000 | 1810*2000 | 4300 | 60 | 51 | 2.2 | |
| 6000 | 1980*2000 | 4550 | 60 | 51 | 2.2 | |
| 7000 | 1930*2440 | 5000 | 60 | 51 | 2.2 | |
| 8000 | 2060*2440 | 5000 | 60 | 51 | 3 | |
| 9000 | 2180*2440 | 5050 | 60 | 51 | 3 | |
| 10000 | 2300*2440 | 5050 | 60 | 51 | 3 | |
| 12000 | 2270*3000 | 5600 | 60 | 51 | 4 | |
| 15000 | 2530*3000 | 5700 | 60 | 51 | 4 | |
| 20000 | 2640*3660 | 6400 | 60 | 51 | 5.5 |
