Specifications
1: continuous sealing.2: steel printing.
3: counting device.
4: stainless steel.
5: horizontal/vertical seal.
[Product name]FR-900 Series Continuous Film Sealer
[Product introduce]
Overview
This series sealer is in the function on continuous carry, seal and print it one operation, and enable to
horizontally. Vertically and with stand, the machine adopts electronic constant temperature mechanism and
stepless speed adopts electric constant temperature mechanism and stepless speed adjusts transmission
mechanism, it can seal plastic film in various kinds of materials.
Using the principle and scope
Adopts high power heat pipe double constant temperature heating, the moment after composite plastic bag
inside film melting point is reached, and then after cooling system with forming embossing wheel, the sealing
after the mouth sealing dense, smooth, behind the embossing wheel with concave / convex word can suppress
date, clear.If the cookie bag , mask, instant noodles all composite plastic film sealing.
Technical parameters
Model | FR-900 |
Voltage | 110V/220V 50-60HZ |
Power | 500W |
Sealing speed | 0-12m/min |
Sealing width | 6-15mm |
Temperature range | 0-300°C |
Max. Loading | 3kg |
Printing type | Steel wheel printing |
N.W | 28KG |
Packing size | 860X430X520mm |
Conveyor speed | 0-12m/min |
Conveyor | PVC |
G.W | 28KG |
Points for attention in use
1. This machine is used to ground.
2. Safety first, the interior of the machine mold temperature, don't put hands.
3.Not recommended for the cable plug, preferably with 63A with leakage air switch.
4.Turn off the machine before the first turn, temperature, over 8-10 minutes off switch, prolongs service life of heating tubes.
5.Normal voltage above 200V can rise above 200 degrees, the highest temperature is 150 degrees below 200V.
6.To regularly on the chain wheel shaft with butter, reduce the abrasion of parts of.
7.Every day after work to clean up the health, especially the conveyor belt.
8.If a failure occurs, the professionals can not open the box, timely and contact us.
