Hfo Power Plant Fuel Water Separator With Control System
Nanjing Kingreat Machinery Co.,ltd is a subsidiary of China State Shipbuilding Corporation (CSSC Group).which was established in 1958, covering an area of 650000m2, there are 2300 staff and employee in our company, 281 of them are technicians and engineers. It has obtained the approvals and certifications of both ISO9001: 2008 quality control system and the military product quality certificate,BV and CE certificates.Some of our machines gained the new technology invent patent.
We are one of the world's leading manufacturers of disc centrifuges, decanters, separation systems and marine equipment. We focus on food production, environmental protection, energy recycling, chemistry and marine. Now ,there are over 150series of decanter centrifuges and disc separators used home and abroad.
This system integrated in a standard 20 FT HQ and adopts IVS4 mode, that is, a set of auxiliary engine can satisfy the four sets of diesel generator unit at the same time.
Container integrated fuel oil supply &booster module , air compression module and fuel oil separation module. These three modules with their control system are relatively independent.
Container integrated HFO supply & booster module, diesel emergency supply and switch, Fuel oil booster, Light and Heavy oil automatically switching , air Compression and fuel oil separation module, and also equipped with relatively independent control system.
- Brief introduction of fuel oil supply & booster module
This module includes heavy oil transportation, filtration, heating, booster,viscosity and temperature control ,light diesel oil emergency booster and light-heavy oil switch. Meanwhile, it is aim to ensure the oil viscosity host fed and the pressure required. And starting diesel oil emergency module while the host fails. When the host starts or stops, it switches diesel for pipeline and equipment cleaning.
- Brief introduction of air compression module
In this module, compressor, air dryer, air filter, air bottles, valve fittings and control system are included. Air compression module is mainly used for diesel engine starting up and also used in the fuel oil supply module for discharging of the self-cleaning recoil filter and in fuel oil separation module for pneumatic three-way valve.
- Brief introduction of fuel oil separation module
In this module, fuel oil separator is the core of heavy oil separation module and will equip with corresponding pumps and valves according to the actual requirements of customers. The control system realizes intelligent fully automatic control by PLC display and Siemens program. This module is mainly used to separate the heavy fuel oil in heavy fuel oil setting tank, and pump to heavy oil daily service tank to supply for fuel oil booster module.
PS: In addition to the three integrated modules in the container, we will also involve in oil tank, heavy and light oil transportation, oil processing and so on.
- Complete engineering package
- Produrement and project management
- Powerhouse including civil works, genset's foundation, steel structure, relevant balance pf palnt equipment(air intakes, pumps and piping, exhaust stacks lo separation/filtration etc)
- Control room and electrical room according to the site design
- Control system, HMI and communication systems
- Cooling system for engines
- Optional heat recovery system
-
Etc
