Home > Products > Disc Separator > Disc Biodiesel Centrifuge for Glycerin Centrifuge
Disc Biodiesel Centrifuge for Glycerin Centrifuge
- Nanjing Shanghai Ningbo
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Centrifuge | |
| Product Type | Other, Biodiesel Centrifuge for Glycerin Centrifuge | Place of Origin | Jiangsu, China | |
| Brand Name | Kingreat | Model Number | PDSV | |
| Voltage | 220,380,440,460V | Power(W) | According to the model | |
| Weight | According to the model | Dimension(L*W*H) | According to the model | |
| Certification | ISO | Warranty | 12months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Biodiesel Centrifuge for Glycerin Centrifuge1.Disc centrifuge
2.Fully automatic
3.CE, ISO
Disc Biodiesel Centrifuge for Glycerin Centrifuge
Bio-diesel oil is green reborn energy, which achieved by the reaction between alcohol (methanol, ethanol ) and fat crop like soy and rapeseed, fat forest fruit like oil palm and yellow wood, fat water vegetable like algae, and also animal fat, wasted edible oil.Bio-diesel oil is used as fuel, being excellent replacement for petroleum diesel oil.Bio-diesel oil is typical "green energy". Which good for the economy continuously developing, and has important strategic meaning at improving energy replacement, reducing environment pressure, controlling the atmospheric pollution.
Model | PDSV-1500 | PDSV-2500 | PDSV-5000 | PDSV-7000P | PDHZ550 | PDRS550 | ||
Capacity (L/h) | 1000-1500 | 2500 (60TPD) | 5000(100TPD) | 7000(150TPD) | 250-300(PTD) | |||
Motor power (KW) | 7.5 | 11 | 15 | 22 | 22 | 18.5 | ||
Discharging type | Part discharging | Part discharging /Manual discharging | Part discharging | Part discharging | Part discharging | Manual discharging | ||
Net weigh (KG) | 1200 | 1030 | 1077 | 1532 | 2580 | 1780 | ||
Overall dimension L × W × H(mm) | 1660x1440x1900 | 1800x1500x1750 | 1269x1187x1495 | 1728×1290×1935 mm
| 1850×1500×1855 | |||
1780×1560×1855 | ||||||||
Centrifuges can be used in the following process stages in virtually all of the following:
1.Separation of methyl ester and glycerine/catalyst/sap/methanol
2.Washing of methyl ester
3.Separation of fatty acids from glycerine.
4.Separation of salts from glycerine.
