Continuous Discharge Large Volume Decanter
Decanters with slow rotation speeds are normally based on horizontal separation technology. Decanters ensure optimum separation efficiency in the case of suspensions with a very high proportion of solids. They are also used for the extraction of constituents from liquids and for concentrating, dewatering and classifying solids.
Decanters designs:
Type: 2-phase separation
Materials: use high-quality stainless steel for all product wetted areas.
Bearings: SKF brand. A special selection and arrangement of bearings provides for long life and exceptional reliability.
Wear protection: welded hard facing or spray coating,ceramic technology.
Food: Fruit and Vegetable juices, Starch, Protein, Molasses, Stillage
Oils and Fats: Fish oil, Gelatine
Environmental protection/Recycling: Drilling mud, Industrial wastewater, Municipal wastewater
Minerals: Graphite, Kaolin, Bentonite
Two phase decanter centrifuge:
Model |
Diameter (mm) |
Bowl speed (rpm) |
Length (mm) |
G-force |
Capacity (m3/h) |
Main motor power (kw) |
Assistant motor power (kw) |
Weight (kg) |
Overall size (L × W × H)(mm) |
PNX409 |
250 |
5500 |
850 |
3493 |
0.2-2 |
15 |
4 |
1020 |
2500 × 650 × 760 |
PNX-414 |
355 |
4000 |
860 |
3175 |
1~10 |
18.5 |
7.5 |
2035 |
2765 × 920 × 1060 |
PNX-416 |
355 |
4000 |
1160 |
3175 |
1~15 |
18.5 |
7.5 |
2122 |
3065 × 920 × 1060 |
PNX-418 |
355 |
4000 |
1460 |
3175 |
1~25 |
22 |
7.5 |
2222 |
3365 × 920 × 1060 |
PDC-1655 |
420 |
3000 |
1450 |
2113 |
10~30 |
55 |
15 |
4600 |
4080 ×1100 × 1420 |
PDC-17-4 |
420 |
3600 |
1680 |
3042 |
3~15 |
30 |
7.5 |
5165 |
3331 × 990 × 1066 |
PDC-18-4.4 |
450 |
3300 |
2000 |
2739 |
10~20 |
37 |
11 |
2739 |
4000 × 1120 × 1239 |
PDC-20 |
500 |
3200 |
2000 |
2860 |
5~45 |
55 |
11 |
4400 |
4489 × 1160 × 1350 |
PDC-21 |
540 |
2800 |
2000 |
2366 |
15~50 |
45 |
15 |
5290 |
4587 × 1285 × 1368 |
PDC-24 |
620 |
3200 |
2480 |
3555 |
15~60 |
Hydraulic station 90 |
8000 |
4650 × 2010× 1200 |
|
PDC-28HH |
720 |
2200 |
2400 |
1975 |
15-80 |
110 |
37 |
9393 |
4800 ×1350 × 1500 |
PS: The above parameters will be subject to the final technical agreement.
