Specifications
Vegetable and Fruit Centrifuge1. PLC control, continuous batch operation
2. No base installation
3. Large capacity
Bottom Discharge Vegetable and Fruit Centrifuge
1) Adopts no-base installation, omits traditional tripod type hanging structure and simplifies the installation process.
2) The basic platform is the work operation platform.
3) All of the fasteners are made of stainless steel.
4) The transmission section is sealed with stainless steel.
5) The airtight packing is made of silicone rubber and equipped with washing and spraying system.
6) The whole machine meets GMP hygienic demand.
7) Adopts opening-cover protection, overheat, overloading and over current protection of the motor, overloading and 8) Full-sealing, CIP system, explosion-proof.
Model |
Basket |
Motor (kw) |
Weight (kg) |
Overall size (L × W × H) (mm) |
||||
|
Diameter (mm) |
Volume (L) |
Capacity (kg) |
Max speed (rpm) |
G-Force |
||||
PPSBD-140 |
800 |
100 |
140 |
1500 |
1008 |
11 |
3000 |
1800 × 1200 × 1670 |
PPSBD-200 |
1000 |
150 |
200 |
1200 |
806 |
15 |
4000 |
2050 × 1500 × 2000 |
PPSBD-400 |
1250 |
280 |
400 |
900 |
567 |
18.5 |
5000 |
2350 × 1650 × 2450 |
PPSBD-540 |
1250 |
400 |
540 |
1000 |
700 |
22 |
5500 |
2400 × 1700 × 2920 |
PPSBD-1200 |
1600 |
900 |
1200 |
850 |
647 |
45 |
8500 |
3000 × 2200 × 3300 |
