Washing Powder Packing Machines
Functions and Features:
All tasks of metering, bag making, filling, sealing, cutting, tear notch, batch No. can be automatically done by this machine.
1. Advanced PLC control to monitor the working status of the machine, including bag length setup, Limited-quantity downtime, Limited-output downtime, output accumulating and display, etc. It is a new and high intelligent machine.
2. Intelligent temperature controller to monitor the temperature of horizontal sealer and vertical sealer through 2 channels.
3. Intelligent optoelectronic switch with strong anti-jamming liability, in case of cursor anomaly of continuous three bags, the machine will stop automatically and alarm.
4. Adjust steplessly packing speed within specified range, not need to stop machine
5. Metering by precision screw to make sure high metering precision.
Applications:
It is Suitable for packing powder materials in the pharmacy, food, agriculture and daily chemical industries. Such as milk powder, bean flour, seasoning, washing powder, etc.
Specifications:
Bag Length: 30~160mm Bag Width: 30~100 mm
Packing Speed: 30~70 Packs/Min (according to different materials and specifications)
Measuring Range: 1~50 ml Measuring Mode: Screw
Bag Making Mode: 3-Side Seal,4-Side Seal or back seal
Power: 1.2Kw / AC 380V / 220V/50Hz
Outer Dimension: Length 700mm×Width 700mm×Height 1700mm Weight: 200Kg
DXD-50F
Item | Specification | Remark |
Filling volume | 0-50g(side seal) 0-100g(back seal) | Adjustable |
Packing speed | 40-70 bags/min, 40-100 bags/min(rotary Cutting) | As per material and filling volume |
Filling device | Screw | |
Sealing type | 3-side sealing or 4-side sealing or back seal | |
Bag size | L50-150mm W40-100mm | |
Controller | Micro-computer controller + digital Display Screen | |
Driver system | Servo motor or step motor A choice between two | |
Voltage | AC220V/380V, 50Hz Or customized as customer request | |
Total power | 1.2Kw(370W+720W) | |
Machine shell | A3 steel or Stainless steel | |
N.W. | 165Kg | |
G.W | 195Kg | |
Dimension | 600 x600 x1600mm | |
Pack Dimension | 800 x 800 x1800mm ( Lx W x H) | |
Applicable films | Plastic composite films or co-ex film like PE,PET/AL/PE, PET/PE, NY/PE, NY etc. | |
