Home > Products > New Product > Liquid Nternal Circulating Stainless Steel Mixer Tank

Liquid Nternal Circulating Stainless Steel Mixer Tank

Name: Liquid Nternal Circulating Stainless Steel Mixer Tank
Brand: Guanyu
Availability: InStock

FOB Price

US$ 5,000 - 12,500 / Set

1 Set(Min. Order)

Port Huangpu
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Mixer Type	Agitator
Product Type	Cosmetic	Application	Liquid
Additional Capabilities	Milling	Place of Origin	Guangdong, China
Brand Name	Guanyu	Model Number	GYM-200L
Max. Loading Capacity	5000L	Voltage	380V,220V or 415V
Power(W)	2.95KW	Dimension(LWH)	8008001500 mm
Certification	CE	Warranty	One year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Super Quality Washing-Up Liquid Nternal Circulating Stainless Steel Mixer Tank

We Have The Advantage Of

Product Description

Item Name	Super Quality Washing-Up Liquid Nternal Circulating Stainless Steel Mixer Tank
Item NO.	GYM-200L
Material	SUS316L/SUS304
Warranty service	1 year
Mixing Method	One-way (bidirectional) frame type scraper stirring
Homogeneous Mode	Bottom Circulation
Openings Way	Side Circulation
Bearing	With Japanese NSK
Seals	With Germany Bergman
Stirring Parameters	With Siemens Motor 0.75KW,Mitsubishi Inverter, Speed 0-63 rev / min
Homogeneous Parameters	With Siemens Motor 5.5KW,Mitsubishi Inverter, Speed 0-3600 rev / min
Electrical Components	Electric / Steam Heating
Heating method	Electric/Steam Heating

Product Features

1. This company produces the vacuum emulsifying type varieties diverse, including homogeneous system points on homogeneous under homogeneous, both inside and outside circulation homogeneous, mixing system and two-way one-way stirring, ribbon stirring;The lifting system is divided into single cylinder and double cylinder lifting, and can be customized according to customer request a variety of meets the demand of high quality products.

2. Triple mixing adopt imported frequency converter speed control, can meet different process requirements;

3. Homogeneous structure of German technology, using imported double mechanical seal effect, emulsifying speed can reach 4200 r/min, highest the highest shear fineness can reach 0.2 5 um;

4. Vacuum deaeration to achieve aseptic requirements, and USES the vacuum materials, especially for powder material using vacuum suction to avoid dust float in the sky;

5. The main pot pot can choose lifting device, convenient cleaning, cleaning effect is more significant, the pot body can choose the dumping of discharging;

6. Pot body adopted three layers of imports of stainless steel plate welding, tanks and pipelines for mirror polishing, full compliance with GMP requirements;

7. According to the technological requirements, heating and cooling material of tank, steam and electric heating two heating methods mainly include;

8. In order to ensure the whole machine control is more stable, using imported electrical appliances, can fully meet international standards;

Product Show

Main Products

Our Factory

Ours company in baiyun district, Guangzhou city, China, From Guangzhou airport to ours company
it will take 15 minutes by car. In this line, we have been engaged in this line for 14 years. Ours machine
can apply to cosmetic, pharmaceutical, daily chemical, food, industrial chemical. We are factory,
professional in:
1. Vacuum emulsifying mixer machine
2. Mixing tank
3. Ro water treatment machine
4. Automatic or semi-automatic filing machine
5. Storage tank
6. Vertical/horizontal pneumatic filling machine
7. Tube filling sealing machine
8. Perfume machine
9. Complete line: making product—filling—capping--Aluminum foil sealing—labeling—printer
date—packing--finished product.
And so on. For more, please go to web:

Customer Group Photo

Our Services

1. Training: Training to the local operator to be carried out by the supplier at the time of installation/
commissioning/ trial run at factory.
2. Warranty: One year
3. Pre-shipment Inspection:
a). Supplier should trial run whole line at supplier's factory before shipment;
b). Supplier has to run the machine at least 1hour for each product;
c). All raw materials for that trial run to be arranged by supplier at their cost.
4. If components were damaged in guarantee period, please take picture of the part and video send
to us, we will accord your condition, and then will teach you how to deal with and put on the parts
through picture or video. We shall send the spare part free of charge for changing, if the components
were damaged beyond guarantee period, we shall supply the spare part at factory cost price.
The related courier fees will be responsible to the buyer.
2. We provide the lifelong maintenance service. (Commissioning fee plus flight tickets, hotel and
dinner fee are all at buyer’s account.)
3. We can provide operating instructions, and take pictures and video to you, then you can follow it operation step by step.

Showroom Display

After Sales Service

The above machine which we supply it to you, we can give
you one years after sales warranty, we can also send our
engineer to you factory to install this equipment and train
your staff, but the Buyer should pay the round air ticket
cost and arrange the hotel accommodation as well as the
means for Seller’s engineer. We will send some free set
of spare parts for you change it.
We also can offer one-stop service for customers, which is product formula, raw material, packing material etc.

Certificate

Transportation And Installation

1. It is generally not packaging, but when loading should take necessary measures to prevent equipment damage (user requirements packing can do STH for sb).
2. Host lifting not serious when the tilt, lest the BabyCenter offset cause an accident.
3. The machine installation does not need to take another foundation, only mat cushion flat base; to regulate activities foot makes the machine level. If users need the machine is installed in the upstairs, the main floor bearing capacity to be > 8000 n / square meter.
4. The machine equipment has been installed, the connection between the pipe before they leave the factory in order to facilitate hoisting transportation and apart, users only need according to the figure shape connect operation and equipment support, and put a part of the pipe flange bolts can be retightened good.
5. In steam heating time, please adjust the jacket steam outlet valve limit pressure of 0.25 Mpa.
6. Electrical wiring, wiring board connection between devices and wire solution are by the users themselves to do. Total power supply connected to terminals in power distribution cabinet of A, B, C, N.
7. Start-up and commissioning such as deal with pipeline and equipment all the screws before joint detail to check it again, cannot have loose.

Operational Address: 102-2, Building B, Bldg. 14, North District, Tongda Industrial Park, Hebian Rd.,
Jiahe Street, Baiyun District, Guangzhou, Guangdong, China (Mainland)
Telephone: 86-020-61196674Tel: 13928795282
Website:
Company Name: Guangzhou Guanyu Machinery Co., Ltd.

FAQ

1. Q: Where is your factory?
A: We are in Guangzhou, China.

2. Q: How can I check the quality?
A: You can fly to our factory to inspect or we take video for you.

3. Q: How will you deliver my goods?
A: We can deliver it by sea or by air.

4. Q: Do I have to learn how to operate this machine?
A: No, you just turn on it, it will work automatically.

5. Q: Where can I get help on this machine?
A: Contact us whenever you need help, or we can arrange oversea engineer to help.

6. Q:Are you a manufacturer or a trading company?
A:We are the manufacturer.

7. Q:What's the payment terms?]
A: T/T,30% deposit and 70% balance before delivery. L/C

8. Q:How to order?
A: You can send me an inquiry, then we could confirm the details through emails or telephone.

9. Q:How much is the transportation freight?
A:The freight depends on the weight and size, also the destination port.

10. Q:This is my first time to import, how can I trust your company and ensure to get the goods
if I order from you?
A:We are alibaba legitimate certification company (VIP), and we support payment terms: L/C.
Escrow, to ensure your safety.

11. Q:There are too many models, i don't know which one to choose?
A: Welcome to contact us through TradeManager, we will recommend according to your
requirement. If during closing time or weekend, Please send mail to us, we will response
within 24 hours.

12. Q: How to ensure that I received the machine undamaged?
A: At first , our package is standard for shipping, before sign in, please be sure product undamaged,
otherwise, pls contact with us within 2days, we've bought insurance for you, we or shipping company will be responsible!
