GY-BTA-450+BM-500 Automatic L type shrink packaging machine
Uses:
Suitable for electrical products, hardwares, softwares, food, printing products, medications, floor boards, ceramics etc's packing.
Performance Characteristics:
1.High temperature and sticky free L bar sealing knife, sealing action without smoking and burned. Sealed part is tidy and clean.
2. Covering Teflon on the sealing knife.
3. After sealing action, packing product go in the shrink tunnel automatically by the conveyor belt.
4. Conveyor belt is adjustable on the high by a hand wheel.
5. BTL-450A has a manual/auto switch. When choose auto function, Whole sealing action controlled by cylinder automatically, with fast packing speed.
6. Double electromagnets make stronger pressure.
7. Adjustable film layer with needle device, it is able to fit different size film, max 550mm.
8.Sealing knife has hot protection device on.
Main Technical Parameters:
Model |
BTL-450 |
BM-500 |
Max Packing Size |
(L+H)=500mm (W+H)=400mm (H)=200mm |
(L)700×(W)450×(H)250mm |
Max Sealing Size |
(L)550×(W)450mm |
(L)1200×(W)500×(H)300mm |
Packing Speed |
800~1200packs/hour |
30~50packs/min |
Electric Supply & Power |
220V/50Hz 1.2kw |
380V/50Hz 12kw |
Air Pressure |
6kg/cm3 |
/ |
Weight |
125kg/135kg |
220kg |
Overall Dimensions |
(L)1550×(W)750×(H)1050mm |
(L)1350×(W)750×(H)1500mm |
Automatic shrink machine
1.Working principle:
This machine adopts electric temperature controller,can adjust from common temperature to 300°c,use infrared ray quartz with hight quality to be heating system and imported tube of high power to be stepless speed regulation,stable electricity,ensure the stable of convey.
2.Application:
This machine widely used in high-volum production shrink packaging,apply for the PVC,POF shrink film,adopt dual turbo-fan so the jet degrees is more powerful and high packaging speed,shrinked effect is more perfect.
3.Technical parameter:
Voltage:220V/50HZ,380V/50HZ.
Delivery speed:0-10m/min,can adjust.
Heat tube:7-10PCS.
Inlet dimension:250/150,300/200,400/200,600/300 and so on,can be made as per requirements.
Minimum order:1set.
Hight quality,competitive price,punctual lead time,welcome to contact us.
