300bar Air Compressor Diving Pcp

Specifications

          300bar Air Compressor  Diving pcp

      300bar Air Compressor Diving pcp has 3 levels compression: Level 1 and level 3 set oil-water separator, The output pressure is not less than 30 MPA. Level 2 and level 3 use fire resistant water glycol hydraulic fluid to lubricate and cool. It is safety and explosion –proof.

Product Parameter

Commodity	GY-15	GY-25
Dimension(mm)	720*240*320	455*300*290
Gas Displacement/minute	15L	25L
Output Pressure	≤ 400bar	≤ 400bar
Voltage/Power	220V/460W	220V/550W
Noise	62DB	72DB
Weight	33KG	30KG
Packing	Standard export wooden case 1set/carton	Standard export wooden case 1set/carton
Delivery Time	3-5 days	3-5 days

Filling time:Filling 6.8L 20MPA air bottle need 55minutes;Filling 6.8L 30MPA air bottle need 82minutes.

Scope of Application

High-voltage examination;

Filling high pressure gas bottle

Usage of 300bar Portable Air Compressor

1.The detection of high pressure vessel, mainly used in the detection of high pressure vessel seal leakage

2.The inflation of line throwi 300bar ng unit, to inflate the gas tank of line throwing device.

3.Pre inflatable air gun, to inflate the gas tank of pre inflatable air gun.

Feature of 300bar Portable Air Compressor

Small volume, Light weight

Low   power,  Low  noise

Pictures of  300bar Portable Air Compressor

Package: Standard Wooden Case

Shipment: 3-5 days after payment

One year guarantee for whole machine

24hours technical support by e-mail

Overseas center service
